• 中国科技核心期刊(中国科技论文统计源期刊)

基于机器视觉的五轴坡口切割机器人控制系统设计

张雪健, 毛业兵, 杨芳, 胡晓兵

张雪健, 毛业兵, 杨芳, 胡晓兵. 基于机器视觉的五轴坡口切割机器人控制系统设计[J]. 焊接, 2021, (2): 14-19,37. DOI: 10.12073/j.hj.20201125002
引用本文: 张雪健, 毛业兵, 杨芳, 胡晓兵. 基于机器视觉的五轴坡口切割机器人控制系统设计[J]. 焊接, 2021, (2): 14-19,37. DOI: 10.12073/j.hj.20201125002
ZHANG Xuejian, MAO Yebing, YANG Fang, HU Xiaobing. Design of five axis groove cutting robot’s control system based on machine vision[J]. WELDING & JOINING, 2021, (2): 14-19,37. DOI: 10.12073/j.hj.20201125002
Citation: ZHANG Xuejian, MAO Yebing, YANG Fang, HU Xiaobing. Design of five axis groove cutting robot’s control system based on machine vision[J]. WELDING & JOINING, 2021, (2): 14-19,37. DOI: 10.12073/j.hj.20201125002

基于机器视觉的五轴坡口切割机器人控制系统设计

基金项目:

中国制造2025四川行动计划(2018ZZ011,2017ZZ018)

详细信息
    作者简介:

    张雪健,1996年出生,硕士研究生;主要从事机器人控制、智能制造的研究。

    通讯作者:

    胡晓兵,1970年出生,博士,教授,博士研究生导师

  • 中图分类号: TG48

Design of five axis groove cutting robot’s control system based on machine vision

  • 摘要: 基于机器视觉的五轴坡口切割机器人控制系统的设计,主要针对五轴坡口切割机器人的机械本体的控制方案的设计,以保证机器人在工作空间内可以完成从加工零件图像采集到加工轨迹生成再到完成坡口切割整个流程。整个控制系统上位机以MFC模块与OPENCV视觉库为基础,下位机以PLC控制单元作为核心。从图像采集与处理、通讯、轨迹计算与运动控制到PLC控制单元的设计与电路驱动元件的选取等方面,提出了具体的解决方案,并通过搭建实验平台,验证了试验设计的可行性。控制系统设计严谨,可实现要求的五轴坡口切割作业。
    Abstract: The design of control system of the five axis groove cutting robot based on machine vision was mainly for the design of control scheme of the machine body of the five axis groove cutting robot. It was guaranteed that the robot could complete the whole process from the image acquisition of processing parts to the generation of machining path and to the completion of groove cutting in the working space. The upper computer of the whole control system was based on MFC module and OpenCV visual library, and the lower computer took PLC control unit as the core. The specific solutions were proposed from the aspects of image acquisition and processing, communication, trajectory calculation and motion control, design of PLC control unit and selection of circuit driving components. The feasibility of the experimental design was verified by building an experimental platform. The control system was strictly designed, which could realize the required five axis groove cutting operation.
  • [1] 刘钊江, 马思乐, 戴昊飞, 等. 基于激光传感器的机器人自适应多层多道焊接[J]. 焊接, 2020(8): 26-32.
    [2] 刘源泂, 宋建, 袁文新, 等. 基于激光视觉的分瓣形封头坡口自动分层切削方法[J]. 压力容器, 2020, 37(10): 15-22.
    [3]

    Guo W J, Li R F, Cao C Q, et al. Kinematics, dynamics, and control system of a new 5-degree-of-freedom hybrid robot manipulator [J]. Advances In Mechanical Engineering, 2016, 8(11): 1-19.

    [4] 田金涛. 自动平板坡口切割机器人视觉系统关键技术研究[D]. 哈尔滨: 哈尔滨商业大学硕士学位论文, 2019.
    [5] 陈宇. 基于视觉伺服坡口切割机器人控制系统的研制[D]. 哈尔滨: 哈尔滨工程大学硕士学位论文, 2012.
    [6]

    Li X L, Quan Z K, Liu D P. Design of control system for 6-DOF manipulator [J]. Materials Science and Engineering, 2020, 772: 012041.

    [7]

    Zhang W B, Zhang C L, Li C B, et al. Object color recognition and sorting robot based on OpenCV and machine vision [C]. 2020 IEEE 11th International Conference on Mechanical and Intelligent Manufacturing Technologies, Cape town, South Africa, 2020: 125-129.

    [8] 王鑫, 许晓安, 杨裕才, 等. 直角坐标机器人控制系统设计与研究[J]. 机电信息, 2020(20): 117-118.
    [9]

    Liu Y N, Hu T L, Ni H P, et al. Design of a PC-based open industrial robot control system integrated with real-time machine vision [C]. 2018 WRC Symposium on Advanced Robotics and Automation (WRC SARA), Beijing, China, 2018:1-6.[)

    [10] 袁丽英, 刘佳, 王飞越. 基于SURF的图像配准改进算法[J]. 探测与控制学报, 2020, 42(2): 65-70.
    [11] 童话, 李建华, 徐凯. AutoCAD表格图形文件中的数据读取[J]. 机械设计与制造, 2005(7): 67-68.
    [12] 白蕾, 王聪慧, 蒋超. 基于早期认知视觉的图像轮廓提取[J]. 国外电子测量技术, 2019, 38(12): 16-20.
    [13] 吴孟桦, 胡晓兵, 李航, 等. 基于图像配准的零件轮廓修正方法[J]. 计算机应用, 2020, 40(4): 1144-1150.
    [14] 刘青亮, 姜秋红. 基于Modbus RTU主站通信协议的PLC监控系统设计[J]. 煤矿机电, 2019, 40(5): 84-86.
    [15] 吴孟桦, 胡晓兵, 赵清祥, 等. 基于双结构光视觉的机器人运动学参数标定方法[J]. 组合机床与自动化加工技术, 2020(6): 37-40.
    [16] 李富国, 李杰. 基于PLC的工业机器人控制系统的研究[J]. 机械研究与应用, 2018, 31(6):163-165.
