Sn含量对Ag-Cu-In合金钎料加工及钎焊性能的影响

Influence of Sn concentration on processability and solderability of Ag-Cu-In alloys

  • 摘要: 研究了Sn元素对Ag-Cu-In合金钎料加工及钎焊性能的影响。结果表明:Ag-Cu-In合金钎料中加入一定量的可以有效降低钎料的熔化温度,当8%Sn元素加入Ag-Cu-In合金中,其熔化温度降低为575~620 ℃,可以加工为0.10 mm厚的带材,钎焊性能良好;随着合金中Sn元素含量的增加,合金钎料中的脆性相增多、变大,导致合金的加工性能变差,不能成型。



    Abstract: The influence of Sn concentration on processability and solderability of Ag-Cu-In alloys were investigated. The result shows that Sn addition in Ag-Cu-In alloys can effectively reduced the melting temperature of the solder. When the alloy with 8% Sn concentration, the melting temperature is 575~620 ℃, the composite solder can be processed into strip, the trip with thickness of 0.1 mm,and the composite solder has good welding performance. However with Sn concentration increasing, when the Sn concentration is more than 8%, excessive Sn addition promotes formation of the coarse second phase particles, which results in the deterioration of processability.



/
