Microstructure and properties of liquid phase diffusion welded joint of GH4413 nickel-based high temperature alloy
-
摘要: 以BNi-2作为填充合金材料使用液相扩散焊对CH4413合金进行了连接,研究了在焊接温度为1 030℃和1080℃,保温时间分别为30 min和60 min等不同焊接参数下CH4413镍基高温合金的接头微观组织、成分分布和显微硬度。扫描电镜(SEM)以及能谱分析结果表明,当焊接温度为1080℃,保温时间为60 min时,钎缝组织中形成了性能良好的固溶体,并且随着焊接温度的升高和保温时间的增加,钎缝的宽度增加,钎料元素向母材中的扩散深度逐渐增加,在母材近缝区形成了金属间化合物。Abstract: Liquid phase diffusion welding of GH4413 alloy was carried out and BNi-2 was used as filler material. The microstructure, composition distribution and microhardness of the welded joint were researched under different welding parameters. Welding temperature was respectively $1030{ }^{\circ} \mathrm{C}$ and $1080^{\circ} \mathrm{C}$, and heat preservation time was respectively 30 min and 60 min . The results of scanning electron microscopy (SEM) and energy spectrum analysis show that, when welding temperature was $1080{ }^{\circ} \mathrm{C}$, and heat preservation time was 60 min, the solid solution with good performance formed in brazing seam. In addition, the width of brazing seam increased, the diffusion depth of brazing filler metal's elements to base metal increased gradually and intermetallic compounds formed near seam section of base metal with the increase of welding temperature and heat preservation time.
-
-
[1] 韩冷.GH99高温合金TP连接工艺与组织性能研究[D].哈尔滨:哈尔滨工业大学硕士学位论文,2010. [2] 杜文浩:CH3128镍基高温合金液相扩散连接工艺及组性能研究[D].哈尔滨:哈尔滨工业大学硕士学位论文,2007. [3] Bose D,Datta A,Cristotaro N D.Comparison of gold-nickel with foils nickel base metallic glass brazing[J].Weld Journal,1991,60(10):29-342.
[4] Umellltlra S,Alldoh Y,Hirono S,et al.Nanoindentation and nanowear tests on amorphous carbon films[J].Philosophical Magazine A,1996,74(1):1143-1157.
[5] 曲文卿.异种材料TIP扩散连接过程及界力学失配性研究[J].北京:北京航空航天大学出版社,2000. [6] 张启运,庄鸿寿,钎焊手册[M].北京:机械工业出版社,1998. [7] 庄鸿寿,E·罗格夏特,高温钎焊[M].北京:国防工业出版社,1989. [8] 毛唯,李晓红,周媛,等.DD3单晶合金TLP扩散焊接头的高温拉伸性能和持久性能[J1.焊接,2008(3):28-31. [9] 毛唯,李晓红,周媛,等.DD6单品合金TLP扩散焊试样匹配性对接头持久性能的影响[J].焊接,2009(2):53-55. [10] Cao Jian,Song Xiaoguo,Zheng Zujin,et al.Effect of diffusion time on interfacial microstructure of TLP joints of DD6 single crystal superalloy[J].Transactions of the China Welding Institution,2011,32(7):13-16.
[11] Lin Tiesong,He Peng,Han Leng,et al.Microstructure analysis of TLP bonded joint of GH99 alloy[J].Transactions of the China Welding Institution,2012,33(3):25-28.
[12] Li Xiaohong,Mao Wei,Zhong Qunpeng,et al.Microstructure and stress-rupture property of TLP diffusion bonded DD3 single crystal superalloy joints[J].Transactions of the China Welding Institution,2012,33(7):1-4.
[13] Lang Bo,Hou Jinbao,Wu Song.Microstructure and mechanical properties of IC10 single crystal superalloy transient liquid phase diffusion bonding joint[J].Transactions of the China Welding Institution,2012,33(8):109-111.
[14] 范玮,毛唯,吴欣,等.GH4169与DD6单晶合金TLP扩散焊接头组织及力学性能研究[J].焊接,2013(8):37-40. [15] Pan Lin,Xing Li,Liu Fencheng,et al.Microstructure of transient liquid phase bonded FGH97 superalloy joint[J].Transactions of the China Welding Institution,2013,34(4):89-92.
[16] 石昆,于治水,李军,等.钎焊保温时间对GH738与GH4169镍基合金真空钎焊接头组织性能的影响[J].热加工工艺,2010,39(1):112-115。 [17] 中国有色金属工业协会.二元合金相图及中间相晶体结构[M].长沙:中南大学出版社,2009. [18] 中国机械工程学会焊接学会.焊接金相图谱[M].北京:机械工业出版社,1987。 [19] 于治水,石昆,李瑞峰.钎焊温度对镍基合金真空钎焊接头组织及硬度的影响[J].热加工工艺,2009,38(17):116-119.
