Vacuum brazing of K9 glass to 2507 stainless steel
-
摘要: 采用不同Ti含量的SnAgCu-x%Ti复合钎料对K9玻璃与2507不锈钢进行了真空钎焊,研究了Ti含量对接头界面组织和力学性能的影响。采用场发射扫描电子显微镜(SEM)、能谱仪(EDS)和光学数码显微镜(OM)对钎焊接头组织结构进行了分析,用万能材料试验机对接头进行了剪切试验测试得到其力学性能,并对断口界面进行了分析。结果表明,接头界面典型组织结构为2507不锈钢/FeSn2/FeSn/Sn(s, s)/Ti-Sn/K9玻璃。随着复合钎料中Ti含量的增加,接头界面中Ti-Sn化合物增多,且剪切强度升高。在钎焊温度为675 ℃,保温时间为10 min时,接头室温剪切强度最高达7.3 MPa。钎焊接头断裂于K9玻璃并延伸至钎料中。Abstract: K9 glass was successfully brazed to 2507 stainless steel by using SnA gC u-x% Ti composite filler with different Ti contents. The effects of Ti content on the microstructure and mechanical properties of the joints were investigated. The microstructures of the brazed joints were investigated with scanning electron microscope( SEM),energy dispersive spectrometer( EDS) and optical digital microscope( OM). The mechanical properties of the joints were measured with universal material testing machine,and the fracture interface were analyzed. The results show that the typical interfacial microstructures are 2507 stainless steel/FeSn2/FeS n/Sn( s,s)/Ti-Sn/K9 glass. With the increase of Ti content,more Ti-Sn compounds form in the joints and the shear strength of the joints increases. The shear strength of the joints reaches a maximum of 7. 3 MPa at the temperature of 675 ℃ and the holding time of 10 min. Shear test indicated that the fracture of the brazed joints does through the K9 glass and extends into the filler close to K9 glass interface.
-
Keywords:
- K9 glass /
- 2507 stainless steel /
- vacuum brazing /
- interfacial microstructure /
- shear strength
-
-
[1] Xu S Z, Yao C Z, Dou H Q, et al. An investigation on 800 nm femtosecond laser ablation of K9 glass in air and vacuum[J]. Applied Surface Science, 2017, 406: 91-98.
[2] Liu C X, Wei W, Fu L L, et al. Optical properties of K9 glass waveguides fabricated by using carbon-ion implantation[J]. Journal of the Korean Physical Society, 2016, 69(2): 169-173.
[3] Zhang Z, Huang J, Geng F, et al. Transient absorption and luminescence spectra of K9 glass at sub-damage site by ultraviolet laser irradiation[J]. Nuclear Instrument and Methods in Physics Research B, 2014, 318(1): 219-222.
[4] 张贝. 高速磨削工艺参数对K9玻璃表面粗糙度的影响规律研究[J]. 组合机床与自动化加工技术, 2018(2): 124-127. [5] Song X G, Zhao Y X, Niu H W, et al. Vacuum brazing of Cf/β-spodumene composites and Ti-6Al-4V alloy using Ag-Cu filler metal[J]. Materials Characterization, 2017, 132: 354-362.
[6] 元琳琳, 唐超, 黄晓猛, 等. 采用Al-Cu-Si-Ni钎料钎焊5A06合金接头组织与性能[J]. 焊接, 2018(6): 33-36. [7] 韩桂海, 赵洪运, 付伟, 等. 钎焊时间对TZM合金与ZrCp-W复合材料接头界面组织及性能的影响[J]. 焊接学报, 2017, 38(1): 69-72. [8] 刘多, 牛红伟, 赵宇, 等. Cf/LAS复合材料的钎焊接头组织与性能分析[J]. 焊接学报, 2017, 38(2): 105-108. [9] 卞红, 田骁, 冯吉才, 等. TC4/Ti60合金钎焊接头界面组织及力学性能[J]. 焊接学报, 2018, 39(5): 33-36. [10] 刘多, 牛红伟, 宋晓国, 等. SiO2陶瓷-TC4接头陶瓷侧的界面行为[J]. 焊接学报, 2017, 38(10): 39-42. -
