SAC105钎料用无卤素助焊剂活性剂的选择

林雨生; 戴宗倍; 刘凤美; 车欣; 易江龙

doi:10.12073/j.hj.20181024001

SAC105钎料用无卤素助焊剂活性剂的选择

1. 沈阳工业大学, 沈阳 410083;
2. 广东省焊接技术研究所(广东省中乌研究院), 广东省现代焊接技术重点实验室, 广州 510651

基金项目:

国家重点研发计划(2017YFB0305700)

广州市科技计划项目(201807010029)

广东省科学院实施创新驱动发展能力建设专项资金项目(2018GDASCX-0113).

详细信息

作者简介:
林雨生,1995年出生,硕士;主要研究领域为电子封装可靠性。

通讯作者:
戴宗倍,1989年出生,博士,工程师

中图分类号: TG425
计量
- 文章访问数: 22
- HTML全文浏览量: 9
- PDF下载量: 20
出版历程
- 收稿日期: 2018-10-23

Selection of activating flux in halogen-free flux used for SAC105 solder

1. Shenyang University of Technology, Shenyang 410083, China;
2. Guangdong Provincial Key Laboratory of Advanced Welding Technology, Guangdong Welding Institute (China-Ukraine E. O. Paton Institute of Welding), Guangzhou 510651, China

摘要

摘要: 选用弱有机酸—乙醇酸和邻苯二甲酸作为活性剂，制备出无卤素松香基助焊剂，用于低银钎料Sn-1.0Ag-0.5Cu (SAC105)/Cu的钎焊。文中考察了弱有机酸的含量及其复配比例对焊接性、铺展率及电气稳定性的影响，发现当有机酸的质量分数为4%，乙醇酸和邻苯二甲酸质量比1∶1时，能够满足SAC105钎料对焊接性及铺展能力的要求，且通过表面绝缘电阻试验结果，发现所研制的助焊剂焊后残留少，具备很好的电气稳定性，能够有效避免潮热环境下的离子迁移失效。结果表明，乙醇酸和邻苯二甲酸具备作为商用助焊剂活性剂的潜力。
- 低银铜SAC105钎料 /
- 无卤素松香基助焊剂 /
- 乙醇酸 /
- 邻苯二甲酸
Abstract: Glycolic acid and phthalic acid were used as weak organic acid activators of halogen-free rosin-based flux that was utilized to solder low silver content SAC105 solder on Cu substrate. The influence of activators content and the corresponding proportional ratio of glycolic acid and phthalic acid on the solderability,spreading rate and electronic stability was studied. It is found that,the adequate solderability and spreading rate of SAC105/Cu can be achieved by using the designed flux with 4 wt. % of weak organic acids consisted of glycolic acid and phthalic acid with a proportional ratio of 1∶ 1. In addition,by using aforesaid flux,very few residues are left with strong electronic stability via the evaluation of surface insulation resistance,which indicates the failure due to ionic migration under hygrothermal condition can be avoided. Therefore,glycolic acid and phthalic acid have the potential for commercial use in soldering flux.
- Sn-1.0Ag-0.5Cu（SAC105） /
- halogen-free rosin-based flux /
- glycolic acid /
- phthalic acid

HTML全文

参考文献(12)

[1]	The European Parliament and of the Council. Restriction of the use of certain hazardous substances in electrical and electronic equipment.[R].European, 2011, 6.
[2]	Shnawah D A, Said S B M, Sabri M F M, et al. High-reliability low-Ag-content Sn-Ag-Cu solder joints for electronics applications[J]. Journal of electronic materials, 2012, 41(9): 2631-2658.
[3]	Sandy B, Lasky R C. Choosing a low-cost alternative to sac alloys for PCB assembly[J]. Smt Surface Mount Technology, 2013.
[4]	Suh D, Dong W K, Liu P, et al. Effects of Ag content on fracture resistance of Sn-Ag-Cu lead-free solders under high-strain rate conditions[J]. Materials Science & Engineering A, 2007, 460:595-603.
[5]	Miric A Z, Grusd A. Lead-free alloys[J]. Soldering & Surface Mount Technology, 1998, 10(1):19-25.
[6]	易江龙, 张宇鹏, 许磊, 等. 无银无铅焊料用免清洗助焊剂研制[J]. 电子元件与材料, 2014(12):74-77.
[7]	Duchi P J, Cetier J, Levasseur L, et al. Optimization of chemistry for a vapour phase process to deflux no clean lead free materials on PCBAs[C].19th Electronics PackagingTechnology Conference (EPTC), 2017: 1-5.
[8]	Pendse R D. High temperature flip chip joining flux that obviates the cleaning process: US, US6417573[P]. 2002.
[9]	National Center for Biotechnology Information. PubChem Compound Database[DB]. CID=757.
[10]	National Center for Biotechnology Information. PubChemCompound Database[DB]. CID=1017.
[11]	Puttlitz K J, Stalter K A.Handbook of lead-free solder technology for microelectronic assemblies[M]. CRC Press, 2004.
[12]	Takemoto T, Miyazaki M. Effect of excess temperature above liquidus of lead-free solders on wetting time in a wetting balance test[J]. Materials transactions, 2001, 42(5): 745-750.
