Effect of trace silicon on properties of Cu-P-Sn powdery brazing filler metal
-
摘要: 采用气水耦合雾化法制备了铜磷锡粉状钎料,并通过添加质量分数为0.5%的硅元素改善粉末球形度和粒度分布,通过粉体材料综合测试仪、比表面积仪、激光粒度仪及差热分析仪检测了两种粉状钎料的基本性能,使用制得的粉状钎料进行火焰钎焊制备拉伸试样,通过力学试验机测试焊缝抗拉强度,通过电子显微镜分析了两种粉状钎料微观形貌及焊缝的微观组织。结果表明,微量硅元素可改善铜磷锡粉末的综合性能,其中松装密度提高17%,振实密度提高15%,比表面积提高60%,粉末粒径由42.93 μm降至30.88 μm,合金粉末熔点降低6℃;微量硅元素可显著提高铜磷锡粉状钎料的球形度,钎缝中形成尺寸较大的胞状α铜基固溶体,硅元素扩散进入基体中,接头抗拉强度略有提升。Abstract: Cu-P-Sn powdery brazing filler metal was prepared by gas-water coupling atomization method,the sphericity andsize distribution were improved by adding 0. 5% mass fraction silicon. The basic properties of two kinds of powdery brazing filler metal were tested by powder material comprehensive tester,specific surface area tester,laser particle size tester and differential thermal analysis tester. The tensile specimen was prepared by flame brazing with the prepared powder filler. The tensile strength of weld was tested by mechanical testing machine. The micromorphology and microstructure of two kinds of powdery brazing filler metal were analyzed by electron microscope. The results showed that trace silicon could improve the comprehensive properties of Cu-P-Sn powders. The bulk density was increased by 17%,the compaction density by 15%,and the specific surface area by 60%. The particle size was reduced from 42. 93 to 30. 88 micron,and the melting point of alloy powder was decreased by 6 ℃ . The sphericity of Cu-P-Sn powdery brazing filler metal could be significantly improved by trace silicon element. A larger cellular alpha-Cu-based solid solution formed in brazing seam and silicon element diffused into the matrix,which slightly improved the tensile strength of the joint.
-
Keywords:
- Cu-P-Sn powdery brazing filler metal /
- silicon element /
- sphericity /
- strength
-
-
[1] 张培磊, 丁敏, 姚舜, 等.两种铜磷钎料对紫铜钎焊的焊接性能和焊缝组织对比[J].机械工程材料, 2009, 33(2):82-85. [2] 杨凯珍, 刘正林, 刘凤美, 等.Sn元素对铜磷钎料性能的影响[J].热加工工艺, 2011, 40(5):41-43. [3] 黄俊兰, 龙伟民, 张冠星.Sn元素对铜磷钎料性能和组织的影响[J].焊接, 2012(3):57-60. [4] 李书珍, 吕登峰, 龙伟民, 等.铜磷锡钎料钎焊黄铜接头组织及性能[J].焊接, 2018(1):38-41. [5] 张冠星, 钟素娟, 程亚芳, 等.基于紫铜/黄铜钎焊的新型无银铜磷锡复合钎料[J].焊接学报, 2017, 38(12):33-36. [6] 李书珍, 吕登峰, 龙伟民, 等.铜磷锡钎料钎焊黄铜接头组织及性能[J].焊接, 2018(1):38-42. [7] 龙伟民, 孙华为, 鲍丽, 等.钎焊材料绿色化研究[J].焊接技术, 2016(1):59-62. [8] 欧阳鸿武, 陈欣, 余文焘, 等.气雾化制粉技术发展历程及展望[J].粉末冶金技术, 2007, 25(1):53-58. [9] 姜锋, 刘辉, 文康, 等.复合添加La, Ce和Si对铜磷钎料润湿性和焊缝微观组织的影响[J].热加工工艺, 2013, 42(11):202-205. [10] 陈安涛.铝硅合金组织及表面张力的研究[D].兰州:兰州理工大学硕士学位论文, 2013. [11] 李鑫, 王永祥.气雾化工艺参数对金属粉末粒度影响的研究[J].有色金属科学与工程, 2002, 16(3):27-29. [12] 欧阳鸿武, 何世文, 刘咏.金属粉末性能对选区激光烧结件质量的影响[J].粉末冶金材料科学与工程, 2004, 9(2):106-111. [13] 丁天然, 曹新民, 钟素娟, 等.多级雾化制粉技术对粉状钎料粒度组成的影响[J].金刚石与磨料磨具工程, 2015(1):68-70. [14] 肖恩奎.铜锡合金铸件的反偏析[J].特种铸造及有色合金, 1987(2):6-9. [15] 于艳梅, 杨根仓, 赵达文, 等.过冷熔体中枝晶生长的相场法数值模拟[J].物理学报, 2001, 50(12):2423- 2428. [16] 陈明文, 陈弈臣, 张文龙, 等.各向异性表面张力对定向凝固中深胞晶生长的影响[J].物理学报, 2014, 63(3):398-406. [17] 李妍, 刘宁.基于激光焊的硅、镁合金粉末对铝/钢异种金属焊接接头性能的影响[J].天水师范学院学报, 2017(5):67-70. -
