AZ31镁合金搅拌摩擦点钎焊接头微观组织和力学性能

窦红强, 翟大军, 侯勇, 杜东方

窦红强, 翟大军, 侯勇, 杜东方. AZ31镁合金搅拌摩擦点钎焊接头微观组织和力学性能[J]. 焊接, 2019, (7): 44-49. DOI: 10.12073/j.hj.20181126002
引用本文: 窦红强, 翟大军, 侯勇, 杜东方. AZ31镁合金搅拌摩擦点钎焊接头微观组织和力学性能[J]. 焊接, 2019, (7): 44-49. DOI: 10.12073/j.hj.20181126002
DOU Hongqiang, ZHAI Dajun, HOU Yong, DU Dongfang. Microstructures and mechanical properties of friction stir spot brazed joint of AZ31 magnesium alloy[J]. WELDING & JOINING, 2019, (7): 44-49. DOI: 10.12073/j.hj.20181126002
Citation: DOU Hongqiang, ZHAI Dajun, HOU Yong, DU Dongfang. Microstructures and mechanical properties of friction stir spot brazed joint of AZ31 magnesium alloy[J]. WELDING & JOINING, 2019, (7): 44-49. DOI: 10.12073/j.hj.20181126002

AZ31镁合金搅拌摩擦点钎焊接头微观组织和力学性能

基金项目:

四川教育厅科学研究项目资助(16ZB0496)

德阳市重点科学技术研究项目(2017ZZ047).

详细信息
    作者简介:

    窦红强,1976年出生,硕士;主要研究方向为金属材料成型技术。

  • 中图分类号: TG454

Microstructures and mechanical properties of friction stir spot brazed joint of AZ31 magnesium alloy

  • 摘要: 研究了几种钎料及硬质相(锌钎料、锡钎料及SiC硬质相颗粒)对镁合金搅拌摩擦点钎焊接头微观组织、剪切力及硬度分布的影响。结果表明,加入锌钎料时,钎料能充分与母材发生冶金反应,生成MgZn2硬质相,焊核区的硬质相阻碍了金属的塑性流动,且在钎焊区会形成较大的钎焊界面,焊接接头剪切力从3.5 kN提升到了5.8 kN,且焊接接头具有较高的硬度。
    Abstract: The effects of several solders and hard phases( zinc solder,tin solder,and Si C hard phase particles) on microstructure,ultimate tensile shear load,and hardness distribution of magnesium alloy friction stir welded joints were investigated. The results showed that when zinc solder was added,the solder would react completely with the base metal to form hard phase of MgZn2. The hard phase of the weld nugget zone hinders the plastic flow of the metal. And a larger brazing interface will be formed in the brazing area. The ultimate tensile shear load of the welded joint was increased from 3. 5 kN to 5. 8 kN. The joint also had a high hardness.
  • [1] 杨合,李落星,王渠东,等.轻合金成形领域科学技术发展研究[J].机械工程学报,2010,46(12):31-42.
    [2]

    Selvarajan R,Balasubramanian V,Razalrose A.Friction stir and pulsed current gas metal arc welding of AZ61A magnesium alloy:a comparative study[J].Materials & Design,2013,49:267-278.

    [3]

    Commin L,Dumont M,Rotinat R,et al.Texture evolution in Nd:YAG-laser welds of AZ31 magnesium alloy hot rolled sheets and its influence on mechanical properties[J].Materials Science& Engineering A,2011,528(4):2049-2055.

    [4] Mayer A,Isakovic J T,庄鸿寿,等.搅拌摩擦点焊[J].焊接,2009(9):6-10.
    [5] 傅田,李文亚,杨夏炜,等.搅拌摩擦点焊技术及其研究现状[J].材料工程,2015,43(4):102-114.
    [6] 叶结和,刘雪松,王素环.不扎透上板对2024-T4铝合金搅拌摩擦搭接焊力学性能的影响[J].焊接学报,2018,39(2):71-74.
    [7] 俞良良,张郑,王快社,等.搅拌摩擦加工对AZ31镁合金微观组织及力学性能的影响[J].材料导报,2018,32(8):1289-1293.
    [8] 梁汉优,刘刚,耿家源.AZ31镁合金搅拌摩擦对接焊接头性能及组织分析[J].热加工工艺,2018,47(15):71-74.
    [9]

    Shen J,Wang D,Liu K.Effects of pin diameter on microstructures and mechanical properties of friction stir spot welded AZ31B magnesium alloy joints[J].Science & Technology of Welding& Joining,2012,17(5):357-363.

    [10]

    Xu R Z,Ni D R,Yang Q,et al.Influence of Zn interlayer addition on microstructure and mechanical properties of friction stir welded AZ31 Mg alloy[J].Journal of Materials Science,2015,50(12):4160-4173.

    [11] 孙金睿,朱海,孙朝伟,等.搅拌头转速对AZ31镁合金厚板搅拌摩擦焊接头力学性能的影响[J].热加工工艺,2018,47(15):204-206,209. [][]
    [12] 尹玉环,胡绳荪,North T H,等.AZ31镁合金搅拌摩擦点焊[J].焊接学报,2011,32(3):101-104,118.
    [13] 吴智.搅拌摩擦焊焊接速度对AZ31镁合金焊接接头性能的影响[J].铸造技术,2018,39(6):1318-1320.
    [14] 王小明,吴海江.冷却速度对AZ31镁合金搅拌摩擦点焊接头组织性能的影响[J].兵器材料科学与工程,2017(2):87-91.
    [15] 杨晓敏,李明珠,董锋,等.温度及搅拌摩擦加工对AZ31镁合金力学性能的影响[J].锻压技术,2017,42(7):169-172.
    [16]

    Kurt A,Uygur I,Cete E.Surface modification of aluminium by friction stir processing[J].Journal of Materials Processing Technology,2011,211(3):313 -317.

    [17]

    Li W Y,Chu Q,Yang X W,et al.Microstructure and morphology evolution of probeless friction stir spot welded joints of aluminum alloy[J].Journal of Materials Processing Technolgy,2018,252:69-80.

    [18]

    Wu L,Wang C,Pokharel D B,et al.Effect of applied potential on the microstructure,composition and corrosion resistance evolution of fluoride conversion film on AZ31 magnesium alloy[J].Journal of Materials Science & Technology,2018,34(11):2084-2090.

    [19]

    Xu R Z,Ni D R,Yang Q,et al.Influencing mechanism of Al-containing Zn coating on interfacial microstructure and mechanical properties of friction stir spot welded Mg-steel joint[J].Materials Characterization,2018,140:197 -206.

    [20]

    Xu R Z,Ni D R,Yang Q,et al.Pinless friction stir spot welding of Mg-3Al-1Zn alloy with Zn interlayer[J].Journal of Materials Science& Technology,2016,32(1):76-88.

    [21]

    Wu H,Song G,Microstructure and properties of brazing joints of magnesium alloy AZ31B[J].Materials Research Innovations,2010,14(2):160 -164.

    [22] 谢吉林,陈玉华,曹文明,等.添加Zn中间层的Mg/Al异种金属搅拌摩擦焊接头界面组织及性能研究[C].兰州:第二十次全国焊接学术会议,2015.
    [23]

    Askariani S A,Pishbin H,Moshref-Javadi M.Effect of welding parameters on the microstructure and mechanical properties of the friction stir welded joints of a Mg-12Li-1Al alloy[J].Journal of Alloys and Compounds,2017,724:859 -868.
