固溶处理对2205双相不锈钢FCAW接头组织及力学性能的影响

李添祺; 张莹莹; 高磊; 张云昊; 刘建美

doi:10.12073/j.hj.20181225002

固溶处理对2205双相不锈钢FCAW接头组织及力学性能的影响

1. 辽宁石油化工大学, 辽宁抚顺 113000;
2. 南昌航空大学, 南昌 330000;
3. 大庆油田有限责任公司, 黑龙江大庆 163000

基金项目:

辽宁省教育厅青年基金(L2017LFW014)

详细信息

作者简介:
李添祺,1988年出生,硕士;从事金属材料焊接技术的研究;已发表论文5篇。

通讯作者:
张莹莹,1981年出生,博士

中图分类号: TG442
计量
- 文章访问数: 28
- HTML全文浏览量: 11
- PDF下载量: 19
出版历程
- 收稿日期: 2018-12-24

Effect of solution treatment on microstructure and mechanical properties of 2205 duplex stainless steels joint by FCAW

1. Liaoning Shihua University, Fushun 113001, Liaoning, China;
2. Nanchang Hangkong University, Nanchang 330000, China;
3. Daqing Oilfield Limited Company, Daqing 163000, Heilongjiang, China

摘要

摘要: 利用气体保护药芯焊丝焊接2205双相不锈钢, 并对焊接接头进行固溶处理。采用金相显微镜、扫描电子显微镜和能谱仪对焊接接头的显微组织和断口形貌进行了观察与分析, 并测试了焊接接头的冲击韧性和显微硬度。结果表明，未经处理的焊接接头熔合区较宽，主要为基体铁素体组织，并且晶粒粗大。热影响区的铁素体和奥氏体边界有少量析出相χ相，铁素体内部有颗粒物析出；焊缝区铁素体内部有σ相和γ₂相析出。1 050 ℃固溶处理后焊接接头析出相和颗粒物消失，奥氏体组织含量提高，冲击断口等轴韧窝增多，韧性增加，硬度值降低。
- 双相不锈钢 /
- 药芯焊丝 /
- 热处理 /
- 析出相
Abstract: 2205 duplex stainless steels（ DSS） were welded by gas-shielded flux-cored wire,and the welded joints are conducted by solution treatment. The microstructures and fracture morphology of weldied joints were analyzed by means of OM,SEM and EDS. The impact toughness and microhardness of welded joints were tested and analyzed systematically. The results show that the fusion zone of untreated welded joint represents a large width,and the organization is mainly composed of ferrite with coarse grains. Few of χ phases precipitate at ferrite-austenite grain boundaries and some carbide appears inside ferrite in heat affected zone（ HAZ）. σ phase and γ₂ phase precipitate inside ferrite in weld.After 1 050 ℃ solid solution treatment,precipitated phase and carbide disappear and the proportion of austenite is higher,which results in high impact toughness and low microhardness,and the number of equiaxed dimples increase in the impact fracture surface.
- duplex stainless steel /
- flux-cored wire /
- heat treatment /
- precipitated phase

HTML全文

参考文献(15)

[1]	Gunn R N.Duplex stainless steels, microstructure, properties and applications[M]. Abington Publishing, Cambridge, United Kingdom, 1997.
[2]	Ezuber H M, El-Houd A, El-Shawesh F. Effects of sigma phase precipitation on seawater pitting of duplex stainless steel[J]. Desalination, 2007, 207(1-3): 268-275.
[3]	Yang S M, Chen Y C, Chen C H, et al. Microstructural characterization of δ/γ/σ/γ₂/χ phases in silver-doped 2205 duplex stainless steel under 800℃ aging[J]. Journal of Alloys and Compounds, 2015, 633: 48-53.
[4]	Badji R, Bouabdallah M, Bacroix B, et al. Effect of solution treatment temperature on the precipitation kinetic of σ-phase in 2205 duplex stainless steel welds[J]. Materials Science & Engineering A, 2008, 496(1): 447-454.
[5]	Li T Q, Zhang Y Y, Gao L, et al. Optimization of FCAW parameters for ferrite content in 2205 DSS welds based on the taguchi design method[J]. Advances in Materials Science and Engineering, 2018.
[6]	喻萍, 尹士科.结构钢用气体保护药芯焊丝的发展趋势[J].机械制造文摘(焊接分册), 2011(5): 18-22, 32.
[7]	He Y L, Zhu N Q, Lu X G, et al. Experimental and computational study on microstructural evolution in 2205 duplex stainless steel during high temperature aging[J]. Materials Science & Engineering A, 2010, 528(2): 721-729.
[8]	Warren A D, Harniman R L, Guo Z, et al. Quantification of sigma-phase evolution in thermally aged 2205 duplex stainless steel[J]. Journal of Materials Science, 2016, 51(2): 694-707.
[9]	Huallpa E A, Monlevade E F, Capó Sánchez J, et al. Use of magnetic barkhausen noise (MBN) to follow up the formation of sigma phase in SAF 2205(UNS S31803) duplex stainless steel[J]. Materials Research, 2016, 19(5): 1008-1016.
[10]	邹德宁, 韩英, 李姣, 等.热处理对2205双相不锈钢焊接接头力学性能的影响[J].机械工程学报, 2011, 47(2): 85-89.
[11]	Calliari I, Zanesco M, Ramous E. Influence of isothermal aging on secondary phases precipitation and toughness of a duplex stainless steel SAF 2205[J]. Journal of Materials Science, 2006, 41(22):7643-7649.
[12]	Sun Q, Wang J, Li H B, et al. Chi phase after short-term aging and corrosion behavior in 2205 duplex stainless steel[J]. Journal of Iron and Steel Research, International, 2016, 23(10): 1071-1079.
[13]	刘雄, 何燕霖, 丁秀平, 等.高温时效对2205双相不锈钢中σ相析出行为的影响[J].材料热处理学报, 2010, 31(3): 48-51.
[14]	李继红, 唐江, 张敏.固溶处理对2205双相不锈钢焊接接头组织与性能的影响[J].金属热处理, 2013, 38(7): 13-16.
[15]	仇潞. 超低碳双相不锈钢焊接及固溶处理工艺研究[D].江苏镇江: 江苏科技大学硕士学位论文, 2015.
