Study on the effect of adaptive control technologyon the quality of spot welding body-in-white
-
摘要: 针对白车身电阻点焊过程存在零件装配不良、焊点分流、板间含涂胶和镀锌板材焊接等影响焊点质量的问题，开启博士力士乐动态电阻自适应控制系统，在不同影响因素下分别进行恒流模式和自适应模式焊接，结合实际焊点动态电阻曲线与合格焊点样本电阻曲线的差异分析，研究自适应控制技术对白车身点焊质量的影响。研究表明，利用自适应控制技术，可有效减少外界干扰对焊接热输入的影响，减少焊接飞溅，提高白车身焊点质量。Abstract: For problems,such as poor assembly of parts,shunt current of welding spots,glue coating and galvanized plate welding,that affect the quality of welding spots during resistance spot welding of body-in-white,the Bosch Rexroth dynamic resistance adaptive control system was opened to carry out constant current mode welding and adaptive mode welding respectively under different influence factors. Combined with the difference between actual dynamic resistance curve of welding spot and the resistance curve of qualified welding spot,effects of adaptive control technology on the quality of spot welding body-in-white were studied. Research showed that adaptive control technology could effectively reduce the influence of external interference on welding heat input,reduce welding spatter and improve the quality of body-in-white welding spots.
-
-
[1] 曾清林, 何深成.浅谈白车身电阻点焊焊接飞溅影响因素及控制预防对策[J].汽车与驾驶维修(维修版), 2019(7):80-81. [2] 刘芯娟, 邵刚.中频逆变直流点焊与工频交流电阻点焊技术优势比较[J].汽车实用技术, 2019(17):195-196. [3] 沈婵媛.轿车白车身电阻点焊焊接缺陷的控制[J].汽车实用技术, 2019(1):148-149, 164. [4] 刘磊, 纵荣荣, 李乐乐, 等.轻量化汽车电阻点焊技术的研究与应用[J].时代汽车, 2019(3):131-134. [5] 沈波, 程哲闻, 程猛.低合金汽车用钢薄钢板电阻点焊工艺研究[J].汽车实用技术, 2019(11):175-177. [6] 齐永成, 廉杰.浅析汽车白车身点焊质量控制措施[J].民营科技, 2018(12):74. [7] 王永生, 范兆博, 王建华, 等.焊接白车身电阻点焊质量控制[C].郑州:第十四届河南省汽车工程科技学术研讨会论文集,2017:426-428. [8] 易铁, 田永强, 蒋冬, 等.不同自适应控制系统在汽车点焊中的应用[J].焊接技术, 2018, 47(10):80-84. [9] Wan X D, Wang Y X, Zhao D, et al.Weld quality monitoring research in small scale resistance spot welding by dynamic resistance and neural network [J].Measurement, 2017,99:120-127.
[10] Wan X, Wang Y, Zhao D.Quality monitoring based on dynamic resistance and principal component analysis in small scale resistance spot welding process[J].The International Journal of Advanced Manufacturing Technology, 2016,86(9-12):3443-3451.
[11] 叶绿, 孔锐斌, 蒋冬.电阻点焊自适应功能启用流程及方法研究[J].汽车工艺与材料, 2017(2):14-18. [12] 施雅丽.汽车白车身焊接质量控制及常用检测与评价方法[J].机电技术, 2017(4):67-72, 95. [13] 张波.点焊恒流模糊控制系统研究[D].西安:西北工业大学硕士学位论文,2003. [14] Ghazanfari H, Naderi M.Expulsion characterization in resistance spot welding by means of a hardness mapping technique[J].International Journal of Minerals Metallurgy and Materials, 2014, 21(9):894-897.
[15] 柳治全.轿车车身焊点质量监控系统的研究[D].兰州:兰州理工大学硕士学位论文, 2012. [16] 李伟.轿车白车身的电阻点焊质量监测系统设计的研究[D].沈阳:沈阳大学硕士学位论文, 2013. [17] Liang Jianyong, Liang Jun, Fang Guodong, et al.Evaluation on spot weld models in structural dynamic analysis of automotive body in white [J].Chinese Journal of Mechanical Engineering, 2011, 24(1):84-90.
[18] 李震生.汽车制造中电阻点焊常见缺陷及应对措施[J].科技创新与应用, 2016(12):117. [19] 林浩磊, 沈洁, 张延松, 等.汽车用镀锌钢板电阻点焊可焊性的研究[J].汽车工程, 2011(6):549-552. -
