模具材料RMD545电弧增材制造工艺

何旺, 韩庆璘, 张广军

何旺, 韩庆璘, 张广军. 模具材料RMD545电弧增材制造工艺[J]. 焊接, 2020, (10): 1-6. DOI: 10.12073/j.hj.20200923002
引用本文: 何旺, 韩庆璘, 张广军. 模具材料RMD545电弧增材制造工艺[J]. 焊接, 2020, (10): 1-6. DOI: 10.12073/j.hj.20200923002
HE Wang, HAN Qinglin, ZHANG Guangjun. Wire and arc additive manufacturing for mold material RMD545[J]. WELDING & JOINING, 2020, (10): 1-6. DOI: 10.12073/j.hj.20200923002
Citation: HE Wang, HAN Qinglin, ZHANG Guangjun. Wire and arc additive manufacturing for mold material RMD545[J]. WELDING & JOINING, 2020, (10): 1-6. DOI: 10.12073/j.hj.20200923002

模具材料RMD545电弧增材制造工艺

基金项目:

国家自然科学基金资助项目(52075121)

国家重点研发计划项目(2018YFB1105800)

详细信息
    作者简介:

    何旺,1995年出生,硕士;主要从事电弧增材制造工艺研究.

    通讯作者:

    张广军,1969年出生,博士,教授

  • 中图分类号: TG442

Wire and arc additive manufacturing for mold material RMD545

  • 摘要: 针对耐磨堆焊药芯焊丝RMD545,进行单层单道熔敷成形工艺试验,分析其成形特点并确定了良好成形工艺区间。选取合适参数进行了多层单道熔敷成形工艺试验,表面成形良好,无明显缺陷。对单层单道和多层单道组织性能进行分析,结果表明,随着电流的增大,冷却速度减慢,单层单道组织中马氏体转变量逐渐减小,贝氏体转变量逐渐增多,硬度随之降低;多层单道熔敷层不同位置经历的热过程不同,组织性能有较大差异,从底部到顶部组织依次为回火马氏体+针状铁素体+少量贝氏体、马氏体+贝氏体+少量针状铁素体、板条马氏体,硬度分布在350~500 HV之间。拉伸试验表明成形件综合力学性能良好,满足相关模具材料修复的性能要求。
    Abstract: This research focused on wire and arc additive manufacturing for mold material RMD545 and the experiment of single layer and single bead deposition forming technology was carried out. The forming characteristics were analyzed and the interval of good forming technology was determined. The multi-ayer single-bead deposition forming technology test was carried out with proper parameters and the surface was well formed without obvious defects. The microstructure and properties of single-layer single-bead and multi-layer single-bead were analyzed. The result showed that with the increase of depositing current, the cooling rate slowed down, the martensite transformation decreased and the bainite transformation increased in single-layer single-bead microstructure, which led to a lower hardness. During the multi-layer single-bead depositing process, different layer had different thermal processes. It made a microstructure variation along the height direction. Microstructures from bottom to top were tempered martensite + acicular ferrite + tiny amounts of bainite, martensite + bainite + tiny amounts of acicular ferrite, and lath martensite. The hardness ranged from 350 HV to 500 HV. The tensile test showed that mechanical properties of the additive manufacturing wall structure could meet the performance requirements of the mold repairing.
  • [1]

    Xu W J, Li W H, Wang Y S. Experimental and theoretical analysis of wear mechanism in hot-forging die and optimal design of die geometry[J]. Wear, 2014, 318(1-2): 78-88.

    [2]

    Ebara R, Kubota K. Failure analysis of hot forging dies for automotive components[J]. Engineering Failure Analysis, 2008, 15(7): 881-893.

    [3]

    Gatat V, Bernhart G, Hervy L. Influence of design and process parameters on service life of nut hot forging die[J]. Journal of Materials Processing Technology, 2004, 147(3): 359-369.

    [4] 夏鹏成, 陈蕴博, 葛学元, 等. 热作模具钢热疲劳性能的研究现状与发展趋势[J]. 金属热处理, 2008, 33(12): 1-6.
    [5] 刘立君, 齐萌, 于义涛, 等. TIG填丝+激光熔凝模具修复工艺分析[J]. 焊接学报, 2018, 39(4): 73-78.
    [6] 艾明平, 来克娴. 5CrNiMo热锻模具堆焊修复工艺研究[J]. 锻压技术, 2009, 34(4): 114-116.
    [7]

    Chen C R, Wang Y, Ou H G, et al. A review on remanufacture of dies and moulds[J]. Journal of Cleaner Production, 2014, 64(1): 13-23.

    [8]

    Sun Y H, Hanaki S, Uchida H, et al. Repair effect of hot work tool steel by laser-melting process[J]. Journal of Material Science & Technology, 2003(19): 91-93.

    [9] 蒋媛媛, 贺定勇, 周正, 等. 电弧喷涂FeBC涂层的微观结构与磨粒磨损性能[J]. 焊接, 2018(4): 47-50.
    [10] 王佳杰, 许建平, 于久灏, 等. 电弧喷涂PS45涂层抗高温氧化性及抗热震性[J]. 焊接, 2019(12): 24-27.
    [11] 李艳丽, 翟大军, 李蓬川, 等. 热锻模具钢5CrNiMo表面堆焊及焊后热处理的组织和高温摩擦磨损性能[J]. 铸造技术, 2018, 39(12): 2838-2841.
