316L不锈钢SLM件与锻件的激光焊接头微观组织与性能

丁宏德; 朱春明; 唐斌; 顾小燕

doi:10.12073/j.hj.20201117002

316L不锈钢SLM件与锻件的激光焊接头微观组织与性能

丁宏德^1,2,
朱春明³,
唐斌^1,2,
顾小燕^1,2,

1. 江苏科技大学, 江苏镇江 212003;
2. 江苏科技大学国家级实验教学示范中心, 江苏镇江 212003;
3. 重庆长安工业集团有限责任公司, 重庆 401120

基金项目:

国家自然科学基金资助项目(51705218)

详细信息

作者简介:
丁宏德,1996年出生,硕士研究生;主要从事增材制造、激光焊接方面的工作

通讯作者:
顾小燕,1983年出生,博士,副教授

中图分类号: TG456.7
计量
- 文章访问数: 38
- HTML全文浏览量: 0
- PDF下载量: 16
出版历程
- 收稿日期: 2020-11-16

Microstructure and properties of laser welded joint between 316L stainless steel SLMed and forged parts

1. Jiangsu University of Science and Technology, Zhenjiang 212003, Jiangsu, China;
2. National Experimental Teaching Demonstration Center, Jiangsu University of Science and Technology, Zhenjiang 212003, Jiangsu, China;
3. Chongqing Changan Industry (Group) Limited Liability Company, Chongqing 401120, China

摘要

摘要: 文中采用激光焊接技术连接316L不锈钢SLM成形件与锻件，进行工艺优化并对其接头微观组织与性能进行研究。结果表明，该接头具有良好的激光焊接性能，无明显缺陷。激光焊接接头和SLM成形件的显微组织为柱状晶粒内的奥氏体基体中的胞状枝晶。与SLM成形件相比，接头表现出较粗的枝晶结构、较低的显微硬度、拉伸性能。该接头的力学性能满足实际应用的要求。各向异性对激光焊接接头的组织和力学性能的影响可以忽略不计。平行于打印方向的SLM成形件与锻件焊接得到的接头，可以得到较细的树枝状结构和较高的拉伸性能。
- 选择性激光熔化成形 /
- 激光焊 /
- 316L不锈钢 /
- 各向异性 /
- 力学性能
Abstract: In this paper,laser welding technology was used to connect 316 L stainless steel SLMed and forged parts. The process optimization was carried out and the microstructure and properties of the joint were studied. The results showed that the joints appeared good laser weldability without obvious defects. Microstructures of the SLMed parts and laser-welded joints consisted of the cellular dendrite in austenite matrix within the columnar grains. Compared with the SLMed parts,the joints exhibited a coarser dendrite microstructure,lower microhardness,tensile properties. Mechanical properties of the joints met the practical application requirements. The anisotropy of SLMed acted a negligible role in determining the microstructure and mechanical properties in the laser-welded joints. The joint obtained by welding SLMed parts parallel to the building direction to forged parts could obtain finer dendrite microstructure and higher tensile properties.
- selective laser melting /
- laser welding /
- 316L stainless steel /
- anisotropy /
- mechanical properties

HTML全文

参考文献(15)

[1]	刘理想, 柏兴旺, 周祥曼, 等. 电弧增材制造多层单道堆积的焊道轮廓模型函数[J]. 焊接学报, 2020, 41(6): 30-35.
[2]	Kruth J P, Froyen L, Van Vaerenbergh J, et al. Selective laser melting of iron-based powder[J]. Journal of Materials Processing Technology, 2004, 149(1-3): 616-622.
[3]	杨天雨, 张鹏林, 尹燕, 等. 激光选区熔化组织分析及人工神经网络力学性能预测[J]. 焊接学报, 2019, 40(6): 100-106.
[4]	唐思熠, 房立家, 孙兵兵, 等. 激光选区熔化Ti6Al4V的工艺参数优化与显微组织[J]. 焊接, 2019(10): 1-6.
[5]	Kale A B, Kim B K, Kim D I, et al. An investigation of the corrosion behavior of 316L stainless steel fabricated by SLM and SPS techniques[J]. Materials Characterization, 2020, 163: 1-34.
[6]	Liu S, Zhang H, Hu J, et al. Microstructure of laser-MAG hybrid welds of sintered P/M steel[J]. Journal of Materials Engineering and Performance, 2013, 22(1): 251-257.
[7]	Correa E O, Costa S C, Santos J N. Weldability of iron-based powder metal materials using pulsed plasma arc welding process[J]. Journal of Materials Processing Technology, 2008, 198(1-3): 323-329.
[8]	陶汪, 王宪, 陈奥, 等. 铝合金激光熔化沉积应力场及力学性能分析[J]. 焊接学报, 2020, 41(4): 62-66.
[9]	Casalino G, Campanelli S L, Ludovico A D. Laser-arc hybrid welding of wrought to selective laser molten stainless steel[J]. The International Journal of Advanced Manufacturing Technology, 2013, 68(1-4): 209-216.
[10]	Prashanth K G, Damodaram R, Scudino S, et al. Friction welding of Al-12Si parts produced by selective laser melting[J]. Materials & Design, 2014, 57: 632-637.
[11]	王云. 典型材料激光选区熔化成形后的焊接特性研究[D].武汉: 华中科技大学博士学位论文, 2017.
[12]	Yang J, Wang Y, Li F, et al. Weldability, microstructure and mechanical properties of laser-welded selective laser melted 304 stainless steel joints[J]. Journal of Materials Science & Technology, 2019, 35: 1817-1824.
[13]	Nahmanya M, Rosenthalb I, Frage Na, et al. Electron beam welding of AlSi10Mg workpieces produced by selected laser melting additive manufacturing technology[J]. Additive Manufacturing, 2015, 8: 63-70.
[14]	Read N, Wang W, Essa K, et al. Selective laser melting of AlSi10Mg alloy: process optimization and mechanical properties development[J]. Materals & Design, 2015, 65: 417-424.
[15]	Rosenthal I, Stern A, Frage N. Microstructure andmechanical properties of AlSi10Mg parts produced by the laser beam additive manufacturing (AM) technology[J]. Metallography Microstructure & Analysis, 2014, 3(6): 448-453.
