B1500HS热成形钢与DP钢的点焊接头拉剪性能

孙浩, 刘成杰, 毕文珍, 郭亚洲, 王武荣, 韦习成

孙浩, 刘成杰, 毕文珍, 郭亚洲, 王武荣, 韦习成. B1500HS热成形钢与DP钢的点焊接头拉剪性能[J]. 焊接, 2022, (5). DOI: 10.12073/j.hj.20210624002
引用本文: 孙浩, 刘成杰, 毕文珍, 郭亚洲, 王武荣, 韦习成. B1500HS热成形钢与DP钢的点焊接头拉剪性能[J]. 焊接, 2022, (5). DOI: 10.12073/j.hj.20210624002
shu
Sun Hao, Liu Chengjie, Bi Wenzheng, Guo Yazhou, Wang Wurong, Wei Xicheng. Tensile-shear properties of resistance spot welded joints of B1500HS hot forming steel[J]. WELDING & JOINING, 2022, (5). DOI: 10.12073/j.hj.20210624002
Citation: Sun Hao, Liu Chengjie, Bi Wenzheng, Guo Yazhou, Wang Wurong, Wei Xicheng. Tensile-shear properties of resistance spot welded joints of B1500HS hot forming steel[J]. WELDING & JOINING, 2022, (5). DOI: 10.12073/j.hj.20210624002
shu

B1500HS热成形钢与DP钢的点焊接头拉剪性能

Tensile-shear properties of resistance spot welded joints of B1500HS hot forming steel

摘要

    摘要
  • 摘要: 文中以3种强度级别的双相钢(DP780,DP980,DP1180)和B1500HS热成形钢的电阻点焊接头为研究对象，研究了DP钢强度对点焊接头拉剪性能的影响，分别观察和分析了接头宏观形貌和微观组织，测试和分析了接头的硬度分布及接头的断裂模式。结果表明，DP钢强度对接头的拉剪强度影响很小，但会影响其断裂模式。B1500HS/DP780的断裂是焊核从DP钢侧拔出，另2种的则是焊核从B1500HS侧拔出，但它们的初始起裂位置均位于亚临界热影响区。B1500HS侧亚临界热影响区软化严重，较基体硬度下降约29%～36%，而DP780无明显软化现象，DP980和DP1180侧的亚临界热影响区软化率分别为17%和25%。说明在异种材料电阻点焊过程中其热影响区的软化程度会影响点焊接头的断裂模式。创新点： 对B1500HS分别与DP780，DP980，DP1180组成的RSW接头展开对比研究。
    Abstract: Three strength levels of DP steel (DP780, DP980,DP1180) and B1500HS resistance spot welded (RSW) joints were prepared and investigated in present paper. The influence of DP steel’s strength on tensile-shear properties of RSW joints were studied. The macroscopic morphology and microstructure of RSW joints were observed and analyzed by ultra-depth microscopy and scanning electron microscope (SEM). The hardness profile of welded joints were measured by Vickers microhardness tester. The results showed that strength of DP steel had negligible impact on tensile-shear strength of RSW joints but its fracture mode. The nugget was pulled out from DP steel side for B1500HS/DP780 RSW joint. The other two nuggets were pulled out from the B1500HS side. Their initial fracture locations were all located in subcritical HAZ (SCHAZ). The SCHAZ on the B1500HS side was seriously softened with 29%～36% hardness loss compared with its matrix. However, there was no obvious softening phenomenon for the SCHAZ on the DP780 side. The softening rates of the SCHAZ on the DP980 and DP1180 sides were 17% and 25%, respectively.Highlights: RSW joints composed of B1500HS and DP780, DP980, DP1180 were comparatively studied.
    • HTML全文
    • 参考文献(16)
  • [1] 孔谅, 刘思源, 王敏. 先进高强钢电阻点焊接头的断裂模式分析与预测[J]. 焊接学报, 2020, 41(1): 12-17.
    [2] 邵天巍, 薛俊良, 万占东, 等. QP980-DP980异种先进高强钢激光焊接头微观组织及力学性能[J]. 焊接, 2019, (7): 5-9.
    [3] Mori K, Bariani P F, Behrens B A, et al. Hot stamping of ultra-high strength steel parts[J]. CIRP Ann-Manuf Technol, 2017,66(2):755-777.
    [4] Tamizi M, Pouranvari M, Movahedi M. Welding metallurgy of martensitic advanced high strength steels during resistance spot welding[J]. Science and Technology of Welding and Joining, 2017, 22(4): 327-335.
    [5] Zhao Y, Zhang Y, Lai X. Analysis of fracture modes of resistance spot welded hot-stamped boron steel[J]. Metals, 2018, 8(10)：1-15.
    [6] Lu Y, Peer A, Abke T, et al. Subcritical heat affected zone softening in hot-stamped boron steel during resistance spot welding[J]. Materials & design, 2018, 155:170-184.
    [7] Baltazar Hernandez V H, Panda S K, Kuntz M L, et al. Nanoindentation and microstructure analysis of resistance spot welded dual phase steel[J]. Materials Letters, 2010, 64(2):207-210.
    [8] Baltazar Hernandez V H, Nayak S S, Zhou Y. Tempering of martensite in dual-phase steels and its effects on softening behavior[J]. Metallurgical & Materials Transactions A, 2011, 42(10):3115-3129.
    [9] Xia M, Biro E, Tian Z, et al. Effects of heat input and martensite on HAZ softening in laser welding of dual phase steels[J]. ISIJ International, 2008, 48(6):809-814.
    [10] 赵洪运,刘洪伟.22MnB5超高强钢焊接组织与性能[J].焊接学报, 2014,35(2):67-69.
    [11] 才贺龙,易红亮,吴迪.22MnB5热成形钢点焊接头组织演变与性能分析[J].焊接学报, 2019,40(3):151-154.
    [12] Paveebunvipak K, Uthaisangsuk V. Microstructure based modeling of deformation and failure of spot-welded advanced high strength steels sheets[J]. Materials & design, 2018, 160:731-751.
    [13] Choi H S, Park G H, Lim W S, et al. Evaluation of weldability for resistance spot welded single-lap joint between GA780DP and hot.-stamped 22MnB5 steel sheets[J]. Journal of Mechanical Science and Technology, 2011,25(6):1543-1550.
    [14] Liang X, Yuan X, Wang H, et al. Microstructure, mechanical properties and failure mechanisms of resistance spot welding joints between ultra high strength steel 22MnB5 and galvanized steel HSLA350[J]. International Journal of Precision Engineering & Manufacturing, 2016, 17(12):1659-1664.
    [15] Eller T K, Greve L, Andres M, et al. Plasticity and fracture modeling of the heat-affected zone in resistance spot welded tailor hardened boron steel[J]. Journal of Materials Processing Technology, 2016,234:309-322.
    [16] Sherepenko O, Jüttner S. Transient softening at the fusion boundary in resistance spot welded ultra-high strengths steel 22MnB5 and its impact on fracture processes[J]. Welding in the World, 2019, 63(1): 151-159.
