• 中国科技核心期刊(中国科技论文统计源期刊)

预热温度对U75V激光熔覆成形性能的影响

寇荣魁, 朱加雷, 焦向东, 童佟, 李丛伟

寇荣魁, 朱加雷, 焦向东, 童佟, 李丛伟. 预热温度对U75V激光熔覆成形性能的影响[J]. 焊接, 2021, (10): 29-33. DOI: 10.12073/j.hj.20210713002
引用本文: 寇荣魁, 朱加雷, 焦向东, 童佟, 李丛伟. 预热温度对U75V激光熔覆成形性能的影响[J]. 焊接, 2021, (10): 29-33. DOI: 10.12073/j.hj.20210713002
Kou Rongkui, Zhu Jialei, Jiao Xiangdong, Tong Tong, Li Congwei. Influence of preheating temperature on U75V laser cladding forming performance[J]. WELDING & JOINING, 2021, (10): 29-33. DOI: 10.12073/j.hj.20210713002
Citation: Kou Rongkui, Zhu Jialei, Jiao Xiangdong, Tong Tong, Li Congwei. Influence of preheating temperature on U75V laser cladding forming performance[J]. WELDING & JOINING, 2021, (10): 29-33. DOI: 10.12073/j.hj.20210713002

预热温度对U75V激光熔覆成形性能的影响

基金项目:

北京石油化工学院京冶新能源技术与装备创新研发中心开放基金(H2019-003/002)

详细信息
    作者简介:

    寇荣魁,1996年出生,硕士;主要从事焊接自动化的研究。

    通讯作者:

    朱加雷,1981年出生,博士,教授

  • 中图分类号: TG456.7

Influence of preheating temperature on U75V laser cladding forming performance

  • 摘要: 研究了预热温度对U75V激光熔覆成形的影响,分析了熔覆层显微组织特征和硬度分布。结果表明,当预热温度低于125 ℃时,熔覆层出现了孔洞和熔深分布不均匀的缺陷,整体尺寸波动较大;125 ℃预热成形的多层熔覆层无明显缺陷。在母材预热后,单层熔覆层熔覆区组织由魏氏组织变化为下贝氏体,热影响区主要为粗晶马氏体,硬度变化较小。多层熔覆层熔覆区组织为柱状晶和等轴晶共存,热影响区的马氏体分布在熔合线附近区域。预热后熔覆层的硬度有所下降,预热对马氏体转变的影响较小。
    Abstract: The effect of preheating temperature on U75V laser cladding forming was studied, and the microstructure and hardness distribution of the cladding layer were analyzed. The results showed that when the preheating temperature was lower than $125^{\circ} \mathrm{C}$, the cladding layer appeared the defects of holes and uneven distribution of penetration depth, and the overall size fluctuated greatly. The multilayer cladding layer preheated at $125^{\circ} \mathrm{C}$ had no obvious defects. After the base material was preheated, the microstructure of the cladding zone in the single-layer cladding layer changed from Widmanstatten to lower bainite, and the heat-affected zone was mainly coarse-grained martensite with little change in hardness. The microstructure of the cladding zone in the multilayer cladding layer was columnar crystals and equiaxed crystals, and the martensite in the heat-affected zone distributed in the area near the fusion line. The hardness of the cladding layer decreased after preheating, and the preheating had little effect on the martensite transformation.
  • [1] 刘凯. “十三五”, 让人期待的中国铁路建设[J]. 建筑, 2016(2): 14.
    [2] 张凯, 皮卫东. 浅析轨头表面接触疲劳伤损的危害, 成因, 检测方法及预防措施[C].西宁:2013年铁道工务探伤技术研讨会, 2013: 110-118.
    [3] 中华人民共和国铁道部. 钢轨电弧焊补条件:TB/T 1631—2002[S]. 2002-07-01.
    [4]

    Seo J W, Kim J C, Kwon S J, et al. Effects of laser cladding for repairing and improving wear of rails [J]. International Journal of Precision Engineering and Manufacturing, 2019, 20(7): 1207-1217.

    [5]

    Yun Xiao, Wang Jing, Zhu Qinghai, et al. Microstructure and wear resistance of Fe-based and Co-based coating of AISI H13[J]. China Welding, 2019, 28(3): 54-60.

    [6]

    Rahman Rashid R A, Barr C J, Palanisamy S, et al. Effect of clad orientation on the mechanical properties of laser-clad repaired ultra-high strength 300 M steel [J]. Surface & Coatings Technology, 2019, 380:1-30.

    [7] 徐连勇, 庞红宁, 赵雷, 等. G115钢CMT+P焊接工艺及组织和性能[J].焊接学报, 2020, 41(8): 1-5.
    [8] 杨东青, 王小伟, 黄勇, 等. 熔化极电弧增材制造18Ni马氏体钢组织和性能[J]. 焊接学报, 2020, 41(8): 6-9.
    [9] 郑韶先, 徐龙强, 赵锡龙, 等. 预置镍基合金片对异种钢UNGW接头组织及性能的影响[J]. 焊接, 2021(1): 1-7.
    [10] 刘爱军, 王国平, 钟志宏, 等. CMT堆焊低合金钢的组织和性能及其冲击断裂行为[J]. 焊接, 2020(4): 11-15.
    [11] 郭辉, 赵爱民, 印珠凯, 等. 预相变马氏体对低温贝氏体相变的影响[C].南昌:第十二届全国固态相变、凝固及应用学术会议, 2016: 106-107.
    [12] 彭谦, 董世运, 康学良, 等. 预热对激光熔化沉积成形12CrNi2合金钢组织与性能的影响[J]. 工程科学学报, 2018, 40(11): 1342-1350.
    [13]

    Hu L H, Huang J, Li Z G, et al. Effects of preheating temperature on cold cracks, microstructures and properties of high power laser hybrid welded 10Ni3CrMoV steel [J]. Materials and Design, 2010, 32(4): 1931-1939.

    [14]

    Su J L, Qiu X M, Xing F, et al. Effect of preheating temperature on microstructure and properties of 42CrMo4/38MnVS6 heterogeneous laser welded joint [J]. Metals, 2019, 9(8): 1-3.

    [15]

    Cai C, Li M, Han B, et al. Numerical simulation iron-based cladding coating with wide-band laser at different preheating temperatures [J]. Applied Laser, 2017, 37(1): 66-71.
