Influence of welding parameters on morphology and mechanical properties of laser scanner welded joints
-
摘要: 为获得高质量镀锌板焊接接头，采用激光扫描焊接方法对1.5 mm厚DP 780镀锌板进行搭接焊，研究激光功率、焊接速度对焊接接头的焊缝成形、显微组织及力学性能的影响。结果表明，激光功率和焊接速度分别在2.5～3.0 kW，25～55 mm/s区间内可获得全熔透焊缝；增大焊接功率，有利于消除焊缝表面咬边，但造成焊缝表面内凹现象严重；全熔透焊接时，增大焊接速度可减少焊缝内凹程度。焊缝中心主要由粗大的板条状马氏体组成，热影响区主要由马氏体和铁素体组成，降低焊接功率或增大焊接速度均可使马氏体组织含量减少及尺寸减小、铁素体含量增加。显微硬度试验表明焊接接头出现软化区，解释了接头拉伸性能在焊接速度55～75 mm/s范围内出现增大现象。焊接功率3.0 kW, 焊接速度45 mm/s工艺参数组合最合适。Abstract: In order to obtain high quality welded joints of galvanized sheets, laser scanner welding method was used for lap welding of 1.5 mm thick DP 780 galvanized sheets, and effects of laser power and welding speed on weld formation, microstructure and mechanical properties of welded joints were studied. The results showed that full penetration welds were obtained when laser power and welding speed were in the range of 2. $5 \sim 3.0 \mathrm{~kW}$ and $25 \sim 55 \mathrm{~mm} / \mathrm{s}$, respectively. Increasing welding power was beneficial to eliminate the undercut on the weld surface, while it caused serious recession on the back of the weld. In full penetration welding, increasing the welding speed reduced the degree of weld recession. The center of the weld was mainly composed of coarse lath martensite and the heat-affected zone was mainly made up of martensite and ferrite. Reducing welding power or increasing welding speed reduced the martensite content and size, and made ferrite content increased. The microhardness test showed that welded joints appeared a softened zone, it was explained that the tensile properties of joints increased in the range of 55 $75 \mathrm{~mm} / \mathrm{s}$ welding speed. The combination of welding parameters, 3 kW welding power and $35 \mathrm{~mm} / \mathrm{s}$ welding speed, was the most suitable.
-
-
[1] 郑森, 程东海, 陈益平, 等. AZ31B镁合金/镀锌钢板电阻点焊接头形成机理[J]. 焊接学报, 2017, 38(2): 83-86. [2] 黄磊, 陈希章, 陈兴, 等.镀锌高强钢激光焊接气孔形成机理[J].红外与激光工程, 2017, 46(S1):7-12. [3] Deng S, Guo Q, Wang H P, et al. Effectiveness of pre-scanning on zinc evaporation in laser spot welding of zinc-coated steels[J]. The International Journal of Advanced Manufacturing Technology, 2020, 106(9): 4423-4436.
[4] Mohammadpour M, Yang B, Wang H P, et al. Influence of laser beam inclination angle on galvanized steel laser braze quality[J]. Optics & Laser Technology, 2020, 129: 1-17.
[5] Müller A, Goecke S F, Rethmeier M. Laser beam oscillation welding for automotive applications[J]. Welding in the World, 2018, 62(5): 1039-1047.
[6] 祁小勇, 李道金, 叶兵, 等.汽车板激光扫描焊接工艺研究[J].激光技术, 2016, 40(6):825-829. [7] 黄瑞生, 邹吉鹏, 孟圣昊, 等.铝合金激光扫描焊接工艺特性[J].焊接学报, 2019, 40(4):61-66. [8] 刘源, 冯爱新, 罗敬文, 等. 振镜扫描式激光叠焊镀锌钢板工艺研究[J]. 应用激光, 2014, 34(6):577-583. [9] Xiong W, Zhang P, Yu Z, et al. Weld zone porosity elimination process of galvanized steel zero-gap lap joints in remote laser spiral welding[J]. Materials Research Express, 2018(6):1-16.
[10] Yang S, Tao W. Remote laser welding of zinc coated steels in a zero-gap lap joint configuration[J]. Journal of Laser Applications, 2017, 29(2): 1-8
[11] Deng S, Wang H P, Lu F, et al. Investigation of spatter occurrence in remote laser spiral welding of zinc-coated steels[J]. International Journal of Heat and Mass Transfer, 2019, 140:269-280
[12] Wan Z, Wang H P, Li J, et al. Novel measures for spatter prediction in laser welding of thin-gage zinc-coated steel[J]. International Journal of Heat and Mass Transfer, 2021, 167: 1-20.
[13] Shi L, Li X, Jiang L, et al. Numerical study of keyhole-induced porosity suppression mechanism in laser welding with beam oscillation[J]. Science and Technology of Welding and Joining, 2021, 26(5): 349-355.
[14] 刘庆永, 孟根巴根, 杜雁冰.搭接间隙对镀锌钢板激光焊接接头组织性能的影响[J].焊接, 2017(11):42-46. [15] 黄磊, 陈希章, 马宏波, 等.DP780镀锌钢激光焊接性能与工艺[J].焊接学报, 2018, 39(8):55-58. -
