不同激光焊接工艺对6005A-T6系铝合金焊接接头高应变速率性能的影响

李洪林; 金鑫; 李勤; 霍英妲; 李褔宝

doi:10.12073/j.hj.20211102003

不同激光焊接工艺对6005A-T6系铝合金焊接接头高应变速率性能的影响

计量
- 文章访问数: 26
- HTML全文浏览量: 8
- PDF下载量: 32
出版历程
- 收稿日期: 2021-11-01
- 修回日期: 2021-12-24
- 发布日期: 2022-02-24

Effect of different laser welding processes on high strain rate performance of 6005A-T6 aluminum alloy welded joints

摘要

摘要: 文中主要以3 mm厚6005A-T6铝合金对接接头为主要研究对象，采用激光填丝焊、激光-MIG复合焊、激光-CMT复合焊3种焊接工艺对其进行焊接，对焊后试样进行高应变速率下单向拉伸试验，得到高应变速率下的真应力-真应变曲线，对拉伸断口进行了SEM分析，对比3种焊接工艺下的高速拉伸性能，拟合3种焊接工艺塑性变形段Johnson-Cook本构方程曲线。研究结果表明，在200 s-1高应变速率下，激光填丝焊接头的抗拉强度最高，而激光-MIG复合焊、激光-CMT复合焊较激光填丝焊的抗拉强度略低；断裂方式均为韧性断裂；3种焊接工艺的Johnson-Cook本构方程曲线与试验曲线拟合较好，可以很好的描述3种焊接工艺在高应变速率下流变应力变化。创新点： (1)对6005A-T6铝合金焊接接头高应变速率动态力学性能进行了研究，通过拟合3种焊接方法塑性变形段Johnson-Cook本构方程曲线，发现在典型应变速率200 s-1高应变速率下，激光填丝焊接头的抗拉强度最高，激光-MIG复合焊、激光-CMT复合焊较激光填丝焊略低。(2)各焊接方法的Johnson-Cook本构方程曲线与试验曲线拟合较好，可以对不同焊接方法接头在高应变速率下的塑性变形进行预测，为实际生产中车身结构的轻量化设计及焊接方式等工艺的优化改进提供数据支撑。
- 6005A-T6铝合金 /
- 激光焊接工艺 /
- 高速拉伸 /
- Johnson-Cook本构方程
Abstract: In this paper,butt joint with 3 mm 6005A-T6 aluminum alloy was taken as the main object of study.The samples were welded by laser wire filling welding,laser-MIG welding and laser-CMT welding,and were tested with a high strain rate to obtain the true stress-true strain curve.Tensile fractures were analyzed by SEM to compare high-speed tensile properties of the three welding methods.Johnson-Cook constitutive equations’parameters of welding processes were calculated correspondingly by fitting to their plastic deformation parts of testing curves.The results showed that the tensile strength of the laser wire filling welded joints was the highest at the high strain rate of 200 s-1,while the joints’tensile strength of the other two welding processes was a little bit lower.The fracture mode was ductile.The curve of Johnson-Cook constitutive equation fit the testing curve well for each welding process,and it accurately described the variation of flow stress under high strain rate.Highlights:(1)The dynamic mechanical properties of 6005A-T6 aluminum alloy welded joints at high strain rates were studied.By fitting the Johnson-Cook constitutive equation curves of the plastic deformation section of three welding processes,it was found that the tensile strength of laser wire filled joints was the highest at the typical high strain rate of 200 s-1,while that of laser-MIG and laser-CMT hybrid welding was slightly lower.(2)The Johnson-Cook constitutive equation curve of each welding process fit well with the test curve,which could predict the plastic deformation of joints of different welding processes under high strain rate,and provide data support for the lightweight design of body structure and the optimization and improvement of welding method and other processes in actual production.
- 6005A-T6 aluminum alloy /
- laser welding processes /
- high-speed tension /
- Johnson-Cook constitutive equation

HTML全文

参考文献(23)

[1]	Sorenson S,Ebbitt G,Smith S,et al.Optimizing transmission loss for lightweight body structures [C]//Grand Rapids,USA:SAE 2017 Noise and Vibration Conference and Exhibition,2017,254(2):1-6.
[2]	王涛.车身铝合金零件关键制造技术和应用现状[J].汽车实用技术,2020(7):187-189.
[3]	陈纪城,陈小梅,常怡婷,等.5056铝合金稳恒磁控激光深熔焊接过程熔池流动与传热行为分析[J].焊接学报,2021,42(4):20-27.
[4]	肖荣诗,陈铠,左铁钏.高强铝合金激光焊接新进展[J].应用激光,2002,22(2):206-208.
[5]	张景泉,黄婷,王栋,等.铝合金光纤激光高速压力焊接[J].焊接学报,2021,42(3):63-69.
[6]	Wang Lei,Xu Xuezong,Wang Kehong,et al.Effect of shielding gas and defocusing on porosity during laser beam welding of 7A52 alloy [J].China Welding,2020,29(3):20-25.
[7]	占小红,欧文敏,魏艳红,等.大型客机机身壁板激光焊接工艺性分析[J].航空制造技术,2014,461(17):42-45.
[8]	范霁康,倪程,徐鸿林,等.3003铝合金激光焊接组织和力学性能[J].焊接,2021(3):22-25.
[9]	聂鑫,杨义成,黄瑞生,等.30 kW光纤激光焊接铝合金离焦量对匙孔行为的影响[J].焊接,2020(7):35-41.
[10]	Song Ping,Li Wenbin,Wang Xiaoming.Study on mechanical properties and constitutive model of 5052 aluminium alloy [J].Materials Science and Technology,2019,35(8):916-924.
[11]	Smerd R,Winkler S,Salisbury C,et al.High strain rate tensile testing of automotive aluminum alloy sheet [J].International Journal of Impact Engineering,2005,32(1-4):541-560.
[12]	Ubertalli G,Matteis P,Ferraris S,et al.High strain rate behavior of aluminum alloy for sheet metal forming processes [J].Metals,2020,10(2):1-10.
[13]	Deng Shanshan,Wang Gang,Chi Runqing,et al.Dynamic mechanical behavior and hypervelocity impact performance of an Al-based nanocrystalline alloy [J].Acta Metallurgica Sinica (English Letters),2017,30(12):1169-1176
[14]	Wang Jianjun,Guo Weiguo,Guo Jin,et al.The effects of stress triaxiality,temperature and strain rate on thefracture characteristics of a nickel-base superalloy [J].Journal of Materials Engineering &Performance,2016,25(5):2043-2052.
[15]	范学领.强冲击载荷下Ti-Al3Ti 金属间化合物复合材料失效机理研究[J].稀有金属材料与工程,2018,47(9):2615-2620.
[16]	胡道春,陈明和.C5191磷青铜的动态拉伸性能和变形机制[J].稀有金属材料与工程,2017,46(6):1518-1523.
[17]	范景莲,龚星,祁美贵,等.高应变率下细晶W-Ni-Fe合金的力学行为与局部绝热剪切带的形成[J].稀有金属材料与工程,2009,38(12):2069-2074.
[18]	郭亚昆,帅茂兵,邹东利,等.应变水平对锆合金动载下塑性变形机制的影响[J].稀有金属材料与工程,2017,46(6):1584-1589.
[19]	王学滨,杨梅,赵扬锋.考虑微小结构相互作用的钛及Ti-6Al-4V真应力-真应变曲线解析解[J].稀有金属材料与工程,2005,34(3):346-349.
[20]	高飞,张先锋,Serjouei Ahmad,等.钽钨合金动态力学行为及其本构模型研究[J].稀有金属材料与工程,2017,46(10):2753-2762.
[21]	KhameiA A,Dehghani K.Effects of strain rate and temperature on hot tensile deformation of severe plastic deformed 6061 aluminum alloy [J].Materials Science &Engineering A,2015,627:1-9.
[22]	刘军,杨黎明,谢书港,等.6061铝合金的动态拉伸性能及其本构模型[J].机械工程材料,2017,41(3):49-53.
[23]	刘盼萍,尹燕,常列珍,等.正火态50SiMnVB钢Johnson-Cook本构方程的建立[J].兵器材料科学与工程,2009,32(1):45-49.
