基于Fluent的窄间隙TIG焊枪结构优化设计

杨宽, 高辉, 周灿丰

杨宽, 高辉, 周灿丰. 基于Fluent的窄间隙TIG焊枪结构优化设计[J]. 焊接, 2022, (8). DOI: 10.12073/j.hj.20211231001
引用本文: 杨宽, 高辉, 周灿丰. 基于Fluent的窄间隙TIG焊枪结构优化设计[J]. 焊接, 2022, (8). DOI: 10.12073/j.hj.20211231001
Yang Kuan, Gao Hui, Zhou Canfeng. Optimization design of narrow gap TIG welding torch’s structure based on Fluent[J]. WELDING & JOINING, 2022, (8). DOI: 10.12073/j.hj.20211231001
Citation: Yang Kuan, Gao Hui, Zhou Canfeng. Optimization design of narrow gap TIG welding torch’s structure based on Fluent[J]. WELDING & JOINING, 2022, (8). DOI: 10.12073/j.hj.20211231001

基于Fluent的窄间隙TIG焊枪结构优化设计

Optimization design of narrow gap TIG welding torch’s structure based on Fluent

  • 摘要: 针对大型工程项目当中的大口径、大厚壁、深窄间隙坡口的管道对接需求,设计了一款窄间隙TIG(NG-TIG)焊枪,并实现高效率焊接。该枪体为非对称的一体化扁平式结构,在间隙宽度为10 mm、深度15 mm的U形坡口内进行焊接试验,发现在窄间隙焊接过程中出现了焊缝成形不连续、焊缝出现气孔及电弧不稳等问题。为了达到理想的焊接工艺效果,文中通过Fluent软件进行了数值模拟仿真分析,对窄间隙TIG焊枪的保护气输送通道及其出口布局进行了结构优化,并且在与传统TIG焊枪的保护气体流量及运动轨迹等方面进行对比后,发现保护气体在钨极周围均匀向外扩散,且速度与传统TIG焊枪的气体保护状态接近,从而确定了窄间隙TIG焊枪的气体保护结构。结果表明,焊枪在焊接电流为120 A,焊接速度为100 mm/min,气体流量在25 L/min的焊接工艺参数下电弧稳定、无飞溅,焊缝成形美观无缺陷。创新点: (1)通过Fluent软件对传统TIG焊枪的保护气体状态进行了仿真,并作为参照对窄间隙TIG焊枪的送气结构进行了优化设计。(2)窄间隙TIG焊枪既继承了传统TIG的优势,又解决了窄间隙焊接过程中电弧不稳、焊缝出现气孔等常见的问题。(3)通过非填丝和填丝,在坡口内和管壁盖面2种工况下进行了焊接试验,确定了窄间隙TIG焊枪的良好适用性。
    Abstract: In view of pipe butt requirements of large diameter, thick wall and deep narrow gap groove in large engineering projects, a narrow gap TIG (NG-TIG) welding gun was designed to achieve high efficiency welding. The gun body was an asymmetrical integrated flat structure. The welding experiment was carried out in U groove with gap width of 10 mm and depth of 15 mm. It was found that there appeared some problems such as discontinuous weld forming, porosity and arc instability in narrow gap welding process. In order to achieve ideal effect of welding process, numerical simulation analysis was carried out by Fluent software in this paper to optimize structure of protective gas transport channel and outlet layout of narrow gap TIG welding gun. After being compared with traditional TIG welding gun in terms of protective gas speed and movement track, it was found that protective gas evenly diffused outward around tungsten electrode and its velocity was close to the gas protection state of traditional TIG welding gun, so as to determine gas protection structure of narrow gap TIG welding gun. The welding experiment showed that welding gun had characteristics of stable arc and no splash in the welding process under welding parameters of 120 A welding current, 100 mm/min welding speed and 25 L/min gas flow, and weld was well formed without defects.Highlights: (1) Fluent software was used to simulate protection gas state of traditional TIG welding gun, which was used as a reference to optimize air supply structure of narrow gap TIG welding gun.(2) Narrow gap TIG welding gun not only inherited advantages of traditional TIG, but also solved common technological problems in narrow gap welding process such as arc instability and weld porosity.(3) Through non-wire filling and wire filling, welding experiments were carried out under two working conditions of groove and pipe wall cover, and good applicability of narrow gap TIG welding gun was confirmed.
  • [1] 付魁军, 倪志达, 林三宝, 等. EH40钢摆动电弧窄间隙MAG焊接头粗晶区微观组织与性能[J]. 焊接, 2020(5): 1-5, 37.
    [2] Gao Fuyang, Mu Zhuangzhuang, Ma Zhaowei, et al. Fine microstructure characterization of titanium alloy laser narrow gap welded joint [J]. China Welding, 2021, 30(3): 31- 38.
    [3] 袁帅, 刘文吉, 李亮玉, 等. 考虑侧壁熔合的摆动电弧窄间隙MAG焊温度场热源模型[J]. 焊接学报, 2018, 39(12): 95-99.
    [4] 张磊, 柳长青, 于静伟, 等. 通过温度场数值模拟分析窄间隙埋弧焊过热区组织演化[J]. 焊接学报, 2016, 37(4): 103-106.
    [5] 徐起, 唐新华, 刘国强, 等. 电弧摆动对窄间隙GMAW横焊打底焊道成形的影响[J]. 焊接, 2020(1): 13-20.
    [6] 王猛, 吕晓春, 梁晓梅, 等. 窄间隙 TIG 横焊侧壁熔合行为[J]. 焊接学报, 2016, 37(6): 118-123.
    [7] 李双, 徐望辉, 李锋, 等. 30 mm厚钛合金TC4磁控电弧窄间隙TIG焊接接头组织及力学性能研究[J]. 焊接, 2018(1): 41-45.
    [8] 薛松柏, 王博, 张亮, 等. 中国近十年绿色焊接技术研究进展[J]. 材料导报, 2019, 33(17): 2813-2830.
    [9] 刘政军, 李宇航, 苏允海. Ar与H2混合气体保护下GTAW电弧特性数值模拟[J]. 焊接学报, 2019, 40(7): 67-71.
    [10] 冯允宣, 张兆栋, 祝美丽, 等. 双丝焊接工艺参数对中厚板打底焊缝形貌的影响[J]. 焊接技术, 2021, 50(2): 21-25.
    [11] 肖磊, 高党寻, 石冠忠, 等. 窄间隙MAG环缝焊工艺在45钢油缸焊接中的研究[J].热加工工艺, 2018, 47(11): 199-202.
    [12] 李鹏飞, 徐敏义, 王飞飞. 精通CFD工程仿真与案例实战[M]. 北京: 人民邮电出版社, 2011.
    [13] 张兆顺, 崔桂香. 流体力学[M]. 北京: 清华大学出版社, 2006.
