S355钢T形接头高周疲劳性能

程艳艳

doi:10.12073/j.hj.20220121001

S355钢T形接头高周疲劳性能

程艳艳^1,2

计量
- 文章访问数: 43
- HTML全文浏览量: 6
- PDF下载量: 6
出版历程
- 收稿日期: 2022-01-20
- 发布日期: 2022-06-24

High-cycle fatigue performance of S355 steel T-joint

Cheng Yanyan^1,2

摘要

摘要: 在工程领域中焊接构件极易产生疲劳断裂，引起各行业广泛关注。文中以T形接头为研究对象，采用MIG焊对S355钢板进行T形接头焊接试验，并对焊接接头进行金相组织和硬度分析。结果表明，焊缝主要为先共析铁素体、珠光体、粒状贝氏体和少量针状铁素体；熔合区成分和组织不均匀，晶粒大小不一致；过热区晶粒较粗大且不均匀；正火区组织主要为铁素体和珠光体，晶粒细小均匀。焊接接头的硬度高于母材，最高硬度出现在热影响区。对T形接头焊接试样进行轴向高周疲劳试验，通过最小二乘法拟合试验数据，得到疲劳S-N曲线。
- S355钢 /
- T形接头 /
- 显微组织 /
- 高周疲劳性能 /
- 断口特征
Abstract: In the field of engineering, fatigue fracture of welded components is very easy to occur, which has attracted extensive attention in various industries.In order to analyze the microstructure and fatigue properties of typical welded components, T-joint were studied in this paper.Welding tests of T-joint of S355 steel were completed by MIG welding, and microstructure and hardness of welded joints were analyzed.The weld mainly contained pro-eutectoid, ferrite pearlite, granular bainite and a small amount of acicular ferrite.Composition and microstructure of fusion zone were not uniform, grain size was not consistent, and grains of overheated zone were coarser and uneven.Microstructure of normalized zone was mainly ferrite and pearlite, and grains were fine and uniform.Hardness of welded joints was higher than that of base metal, and hardness of heat-affected zone was the highest.Axial high-cycle fatigue tests on welded specimens of T-Joints were conducted, test data was processed and fitted by the least square method, and S-N curve was obtained.
- S355 steel /
- T-joint /
- microstructure /
- high-cycle fatigue property /
- fracture characteristics

HTML全文

参考文献(16)

[1]	杨广雪，刘志明，李广全，等.基于等效结构应力法的焊接构架疲劳损伤评估[J].铁道学报，2020，42(7):73-79.
[2]	王文静，刘志明，李强，等.CRH2动车转向架疲劳强度分析[J].北京交通大学学报，2009，33(1):5-9.
[3]	王元良，骆德阳，王一戎.我国高速列车焊接技术及其新发展[J].电焊机，2008，38(8):8-12.
[4]	Sun J M，Hensel J，Klaseen J，et al.Solid-state phase transformation and strain hardening on the residual stresses in S355 steel weldments[J].Journal of Materials Processing Technology，2019，265:173-184.
[5]	李凯，何广忠，王春生，等.接头组对间隙对激光电弧复合焊背部成形的影响[J].城市轨道交通研究，2021，24(2): 131-133.
[6]	刘博维.S355J2W 耐候钢焊接接头组织及性能研究[D].北京: 北京交通大学硕士学位论文，2012.
[7]	Li Tianci，Zhang Lele，Chang Chao，et al.A uniform-gaussian distributed heat source model for analysis of residual stress field of S355 steel T welding[J].Advances in Engineering Software，2018，126:1-8.
[8]	Wang Feixiang，Yang Xinqi，Yin Yayun，et al.Thermal process influence on microstructure and mechanical behavior for friction taper plug welding in structural steel S355[J].The International Journal of Advanced Manufacturing Technology，2017，88(9-12):3459-3466.
[9]	许鸿吉，金光，宋冰昕，等.S355钢焊接接头的组织与力学性能[J].理化检验:物理分册，2008(11):600-603.
[10]	陆善平，王鑫，李殿中，等.焊后退火工艺对高速列车转向架焊接接头组织和性能的影响[J].焊接，2011(5):2-5.
[11]	严春妍，易思，张浩，等.S355钢激光-MIG复合焊接头显微组织和残余应力[J].焊接学报，2020，41(6):12-18.
[12]	赵轶磊.S355J2W+N耐候钢板高频脉冲MAG焊T形接头全熔透焊接工艺及组织和性能研究[D].大连:大连交通大学硕士学位论文，2020.
[13]	张雪红.厚板低碳钢激光-电弧复合焊与MAG焊接头组织研究[J].焊接，2015(1):33-36.
[14]	Lewandowski J，Rozumek D，Marciniak Z，et al.Fatigue crack growth in welded S355 specimens subjected to combined loading[J].Fracture and Structural Integrity，2019，13(48):10-17.
[15]	Duncheva G，Maximov J，Ganev N，et al.Fatigue life enhancement of welded stiffened S355 steel plates with noncircular openings[J].Journal of Constructional Steel Research，2015，112:93-107.
[16]	Technical Committee: ISO/TC 44/SC 10 Quality Management in the Field of Welding.Specification and qualification of welding procedures for metallic-welding procedure test-part1：arc and gas welding of steels and arc welding of nickel and nickel alloys，ENISO15614-1:2017[S].2017-06.
