数字式逆变埋弧焊机IGBT短路保护的试验研究
IGBT short circuiting protection in digital submerged arc welding inverter
-
摘要: 为提高大功率数字埋弧焊机全桥逆变主电路中IGBT短路保护的准确性和焊机的可靠性，对其逆变主电路中IGBT的短路模式进行了分析，设计了一款IGBT驱动器。通过采用抗干扰的IGBT短路试验测试方案，准确、可靠的完成了IGBT短路保护测试。与Concept公司的2SC0106T驱动器短路保护测试结果对比后，结果表明,设计的IGBT驱动器短路保护功能良好，保护时间短，关断电压尖峰小，抗干扰能力强，有一定的工程应用价值。Abstract: In order to improve the veracity of IGBT short circuiting protection in full bridge inverter main circuit of high power digital submerged arc welding power source, and the reliability of the welding machine. The IGBT short circuiting mode was analyzed in the main circuit of full bridge inverter, and an IGBT driver with the short circuiting protection function was designed. The IGBT short circuiting protection was tested accurately and reliably by an anti-jamming measuring method. Compared with the 2SC0106T driver of Concept Company, the experimental results show that the IGBT driver has high performances in the short circuiting protection, such as short time of protection, lower short circuiting voltage spike and strong anti-interference capacity. It can be applied to practical engineering.
-
-
[1] 张晨曦, 汪 苏, 梅 寒. 基于逆变埋弧焊电源系统的模型参考自适应控制[J]. 电工技术学报, 2015, 30(1): 128-132. [2] 黄石生, 何宽芳, 孙德一, 等. 数字化控制的埋弧自动焊装备的研制[J]. 焊接学报, 2008, 36(8): 128-132. [3] 朱 磊, 王振民. WBG功率器件及其在弧焊逆变器领域的应用[J]. 焊接, 2016(7): 14-16. [4] 柳长青, 孟兆军, 金光日, 等. 大厚度窄间隙埋弧焊设备的研制[J]. 机械制造文摘——焊接分册, 2011(1): 47-49. [5] 潘江洪, 苏建徽, 杜雪芳. IGBT高压大功率驱动和保护电路的应用研究[J]. 电源技术应用, 2005 ,8(11): 51-58. [6] 李 孟, 王振民, 朱 磊. 中厚板等离子切割电源数字化PID调控策略及实验研究[J]. 焊接, 2016(6): 18-21. [7] 黄建伟, 刘国友, 余 伟, 等.新型无损IGBT短路耐性测试电路[J]. 半导体检测与设备, 2016, 41(1): 70-75. [8] 林 德.功率半导体——器件与应用[M]. 肖 曦,李 虹,李 敏,等译.北京:机械工业出版社, 2009. [9] 柳舟洲, 同向前. 大功率IGBT短路保护机理的分析[J]. 电气传动, 2015, 45(3): 77-80. [10] 任华清, 傅 强, 苏桂国, 等. 高功率密度的IGBT驱动电路研究[J]. 机械与电子, 2015(8): 56-58. [11] Amit Kumar Jain, Ranganathan V T. VCE sensing for IGBT srotection in NPC three level converters causes for spurious trippings and their elimination [J]. IEEE Transactions on Power Electronics, 2011, 26(1): 298-307. [12] 李东鹏, 孙耀杰, 林燕丹, 等.开关管失效与其检测保护手段的研究[J]. 光源与照明, 2015, 4 (12): 5-8, 15. [13] 杨慧娜, 柏树青. 高频变压器不同绕组结构对分布电容的影响[J]. 华北电力大学学报(自然科学版), 2014, 41(4): 48-55. [14] 赵志英, 龚春英, 秦海鸿. 高频变压器分布电容的影响因素分析[J]. 中国电机工程学报, 2008, 28(9): 55-60. [15] 蒋清健. 基于卡尔曼预测的逆变焊接电源信号处理方法[J]. 焊接, 2016(4): 62-64.
