K4169高温合金机匣的精密脉冲弧焊修复技术

周冠男, 曲伸, 李英, 宋文清, 杨烁, 李晓光

周冠男, 曲伸, 李英, 宋文清, 杨烁, 李晓光. K4169高温合金机匣的精密脉冲弧焊修复技术[J]. 焊接, 2017, (5): 60-63.
引用本文: 周冠男, 曲伸, 李英, 宋文清, 杨烁, 李晓光. K4169高温合金机匣的精密脉冲弧焊修复技术[J]. 焊接, 2017, (5): 60-63.
Zhou Guannan, Qu Shen, Li Ying, Song Wenqing, Yang Shuo, Li Xiaoguang. Precision pulsed repair-welding of K4169 alloy casing[J]. WELDING & JOINING, 2017, (5): 60-63.
Citation: Zhou Guannan, Qu Shen, Li Ying, Song Wenqing, Yang Shuo, Li Xiaoguang. Precision pulsed repair-welding of K4169 alloy casing[J]. WELDING & JOINING, 2017, (5): 60-63.

K4169高温合金机匣的精密脉冲弧焊修复技术

Precision pulsed repair-welding of K4169 alloy casing

  • 摘要: 精密脉冲弧焊技术具有适应性强、灵活简便、可精确控制热输入等优势,采用该工艺对3 mm厚K4169板材进行焊接试验。结果表明,焊缝组织呈细枝晶形态,并析出细小均匀的沉淀强化相,X射线检测结果表明焊缝内无缺陷形成,接头中焊缝处硬度较母材低,接头室温拉伸性能、高温抗拉强度均与母材相当。采用该工艺对机匣零件裂纹缺陷进行了修复试验,检测结果表明修复质量满足使用要求,即精密脉冲弧焊技术可以应用于机匣零件的裂纹修复。
    Abstract: Due to the characteristics of precision pulsed arc welding,such as compatibility,flexibility and the precise control of heat input,the welding experiments were carried out on K4169 alloy sheet with 0.2 mm in thickness.The results show that the microstructure is dendritic morphology with uniform and tiny strengthening precipitation.Furthermore,the welding defect is not free by X-ray inspection.Tensile properties of the joints at room temperature and 650 ℃ are equal to that of the base metal,but show lower hardness.The crack was repaired by precision pulsed arc welding and the result was qualified by the product quality inspection institutions.The conclusion proved precision pulsed arc welding can be applied to the crack repairing of casing.
  • [1] 王莉莉,陈云翔,王 政.再制造工程在某型军用航空发动机上的应用[J].航空制造技术,2009(6):69-71.
    [2] 高子强,晁耀杰,张义文,等.钛合金精密脉冲TIG焊的工艺研究[J].航空维修与工程,2016(6):61-63.
    [3] 高 硕.金银贵金属精密脉冲TIG焊接工艺研究[D].沈阳:沈阳大学硕士学位论文,2014.
    [4] 李 跃.精密TIG焊接技术在精密工件焊接中的应用研究[J].焊接技术,2001,30(4):25-26.
    [5] 徐庆钟,李方义,丁 韬,等.HT250冷焊表面残余应力试验[J].焊接学报,2012,33(10):33 -36.
    [6] 程江波,梁秀兵,陈永雄,等.再制造电弧喷涂成形层的残余应力分析[J].焊接学报,2008,29(6):17-20.
    [7] 张晓东,董世运,王志坚,等.激光再制造金属零件熔覆层组织及耐磨性能[J].焊接学报,2010,31(2):75-78.
    [8] 文元美,黄石生,吴开源,等.双丝脉冲MAG焊两种电流相位关系的焊接行为分析[J].焊接学报,2010(1):59-62,66.
    [9] Ye X,Hua X,Wu Y,et al.Precipitates in coarse-grained heat-affected zone of Ni-based 718 superalloy produced by tungsten inert gas welding[J].Journal of Materials Processing Technology,2014(217):13-20.
