窄间隙摆动电弧焊的传感信号处理
Sensing signal processing of narrow gap weaving arc welding
-
摘要: 在研究国内外电弧传感信号处理方法的基础上,考虑到窄间隙摆动电弧焊的传感信号容易受到噪声的干扰,提出了一种新的组合滤波法,包括削波处理、中值滤波和傅里叶滤波,对采集的电流信号进行滤波处理并在Matlab中进行仿真。结果表明,该滤波方法有效地改善了电流波形,提高了电流信号的信噪比。然后进行了不同偏差条件的焊接试验,通过比较理论偏差与提取的实际偏差,证明了该滤波方法的可行性。Abstract: Based on the existing arc sensing signal processing theory and method at home and abroad, taking into account the narrow gap weaving arc welding of the sensor signal susceptible to noise interference, a new combinatorial filtering method was proposed, which includes the clipping processing, the median filtering and the Fourier filtering. The collected current signals were filtered and simulated in Matlab. The results show that the proposed method can effectively improve the current waveform and the signal to noise ratio of the current signal. The welding experiments with different deviation conditions show that the proposed filtering method is feasible.
-
Keywords:
- weaving arc /
- clipping /
- median filter /
- fourier filter
-
-
[1] 熊震宇,张 华,贾剑平,等. 旋转电弧传感器的研制[J]. 传感器技术,2003(7): 5-9. [2] 曾智英,张 华,叶艳辉,等. 旋转电弧传感器焊缝跟踪信号的采集与处理[J]. 焊接技术,2012(7): 17-22. [3] 曾 露,孟正大,龚烨飞. 脉冲GMAW焊的摆动电弧传感信号处理[J]. 中南大学学报(自然科学版),2013(2): 329-333. [4] 潘际銮. 现代弧焊控制[M]. 北京:机械工业出版社,2000: 175-267. [5] 尹 力,洪 波,屈岳波,等. 旋转电弧脉冲GMAW焊的信号处理[J]. 焊接技术,2006(6): 52-54. [6] 周 洪,孟正大. 电弧传感焊缝跟踪的信号处理 [J]. 华中科技大学学报(自然科学版),2008(10): 122-125. [7] 何文平,吴 琼,成海英,等. 不同滤波方法在去趋势波动分析中去噪的应用比较[J]. 物理学报,2011(2): 818-226 .
