时效温度对Sn-0.7Cu-xFe钎焊接头可靠性的影响

宋兵兵, 杨莉, 蒋立诚, 于华宽, 相积岑

宋兵兵, 杨莉, 蒋立诚, 于华宽, 相积岑. 时效温度对Sn-0.7Cu-xFe钎焊接头可靠性的影响[J]. 焊接, 2017, (11): 17-20.
引用本文: 宋兵兵, 杨莉, 蒋立诚, 于华宽, 相积岑. 时效温度对Sn-0.7Cu-xFe钎焊接头可靠性的影响[J]. 焊接, 2017, (11): 17-20.
Song Bingbing, Yang Li, Zhou Shiyuan, Wang Guoqiang, Shi Xiaolong. Effect of aging temperature on reliability of soldered joint with Sn-0.7Cu-xFe filler metal[J]. WELDING & JOINING, 2017, (11): 17-20.
Citation: Song Bingbing, Yang Li, Zhou Shiyuan, Wang Guoqiang, Shi Xiaolong. Effect of aging temperature on reliability of soldered joint with Sn-0.7Cu-xFe filler metal[J]. WELDING & JOINING, 2017, (11): 17-20.

时效温度对Sn-0.7Cu-xFe钎焊接头可靠性的影响

基金项目:

国家自然科学基金资助项目(项目编号:51401037,51505040);江苏省科技厅工业支持项目(项目编号:BK20141228)。

详细信息
    作者简介:

    宋兵兵,1992年出生,硕士研究生。主要研究方向为电子封装。

    通讯作者:

    杨莉,1966出生,博士,教授。主要从事材料加工及表面强化方面的教学和科研工作,已主持完成省部级以上项目10余项。

  • 中图分类号: TG407

Effect of aging temperature on reliability of soldered joint with Sn-0.7Cu-xFe filler metal

  • 摘要: 研究了时效温度对钎料Sn-0.7Cu及Sn-0.7Cu-0.05Fe钎焊接头微观组织和接头拉伸强度及断口形貌的影响规律。结果表明:随着时效温度提高,焊点组织粗化,钎料中Cu6Sn5化合物形貌由针状向棒状转变,且长大趋势较明显,Fe颗粒的添加可以延缓时效过程中Sn-0.7Cu-x Fe接头微观组织中Cu6Sn5的粗化程度;钎焊接头抗拉强度随着时效温度提高呈现下降趋势,且在相同时效温度下钎料Sn-0.7Cu-0.05Fe钎焊接头抗拉强度均高于Sn-0.7Cu;随着时效温度提高,Sn-0.7Cu和Sn-0.7Cu-0.05Fe钎料钎焊接头断口形貌主要由韧窝和河流解理花样组成,接头的断裂机制随时效温度的升高由塑性断裂逐渐转变为脆性断裂。
    Abstract: The effects of aging temperature on the tensile strength, fracture morphology and microstructures of soldered joints with Sn-0.7Cu and Sn-0.7Cu-0.05Fe filler metals were investigated. The results show that the morphology of Cu6Sn5 compound in the solder is changed from needle-shape to rod-shape with the increase of aging temperature. The addition of Fe particles can decrease the coarsening degree of Cu6Sn5 in the microstructure of joint with Sn-0.7Cu-xFe solder during the aging process. The tensile strength of soldered joint with Sn-0.7Cu-0.05Fe solder is higher than that with Sn-0.7Cu solder at the same aging temperature. The fracture of joints with Sn-0.7Cu and Sn-0.7Cu-0.05Fe solders are mainly composed of dimple and river cleavage pattern. The fracture mechanism of the joint is changed from plastic fracture to brittle fracture during the range of the aging temperature.
  • [1] 向可.热载荷下无铅焊点可靠性电测方法研究[D].长沙:中南大学硕士学位论文,2008.
    [2] 朱路,杨莉,宋兵兵,等.纳米Ag颗粒对Sn-58Bi无铅钎料组织及焊点可靠性的影响[J].焊接,2017(7):42-44.
    [3] 杨雪霞.电子封装中金属间化合物力学性能的研究及焊点可靠性分析[D].太原:太原理工大学博士学位论文,2013.
    [4] 张宁,邵浩彬,时孝东,等.基板间距对超声协振复合钎焊SnBi-xAl2O3微焊点组织及性能的影响[J].焊接,2016(3):40-44,75.
    [5] 颜秀文,丘泰,张振忠.无铅电子封装材料及其焊点可靠性研究进展[J].电子元件与材料,2006(3):5-8.
    [6] 元鑫.多芯片组件(MCM)焊点可靠性的有限元模拟与寿命的预测[D].天津:天津大学硕士学位论文,2006.
    [7] 杨洁,张柯柯,周旭东,等.微连接焊点可靠性的研究现状[J].电子元件与材料,2005(9):58-61.
    [8] 杜长华,陈方,杜云飞. Sn-Cu、Sn-Ag-Cu系无铅钎料的钎焊特性研究[J].电子元件与材料,2004(11):34-36.
    [9] 何大鹏,于大全,王来,C M L Wu.铜含量对Sn-Cu钎料与Cu、Ni基板钎焊界面IMC的影响[J].中国有色金属学报,2006(4):701-708.
    [10] 史益平,薛松柏,王俭辛,等.Sn-Cu系无铅钎料的研究现状与发展[J].焊接,2007(4):14-18.
    [11] 李广东,史耀武,雷永平,等.微量元素改性Sn-0.7Cu系无铅钎料的研究进展[J].电子元件与材料,2009,2(28):70-73.
    [12] 葛进国,杨莉,刘海祥,等.Sn0.7Cu-xNi无铅钎料界面组织与力学性能的研究[J].热加工工艺,2015,21(44):237-239.
    [13] 闫焉服,陈拂晓,朱锦洪,等.Ag颗粒含量对Sn-Cu基复合钎料性能的影响[J].材料研究学报,2007,21(1):102-106.
    [14]

    Yang L, Zhang Y C, Dai J, et al. Microstructure interfacial IMC and mechanical properties of Sn-0.7Cu-xAl (x=0 -0.075) lead-free solder alloy[J]. Materials and Design,2015,67(5):209-216.

    [15] 周许升,龙伟民,沈元勋,等.Sn-0.7Cu无铅钎料显微组织及力学性能在时效过程中的演变[J].焊接,2013(11):16-19.
    [16] 马超力,薛松柏,李阳,等.时效对Sn-Cu-Ni-xPr/Cu焊点组织与性能的影响[J].焊接学报,2014,35(3):85-88.
    [17]

    Mahdavifard M H, Sabri M F M, Said S M, et al. Effects of Fe and Bi minor alloying on mechanical, thermal, and microstructural properties of Sn-0.7Cu solder alloy[J]. Journal of Electronic Materials, 2016, 45(7): 3673-3682.

    [18] 葛进国,杨莉,刘海祥,等.Fe对Sn0.7Cu无铅钎料显微组织和力学性能的影响[J].热加工工艺,2016,2(45):205-210.
    [19]

    Yang L, Ge J, Zhang J, et al. Investigation on the microstructure, interfacial IMC layer, and mechanical properties of Cu/Sn-0.7Cu-xNi/Cu solder joints[J]. Journal of Electronic Materials,2016,7(45):3766-3775.
