Analysis on fillet loose of stainless steel tube by high-frequency induction brazing
-
摘要: 应用高频感应钎焊对1Cr18Ni9Ti不锈钢导管和不锈钢管弯头进行焊接,焊接后钎角处存在疏松缺陷。为了研究疏松组织形貌,采用金相显微镜(OM)、扫描电镜(SEM)、能谱分析仪(EDS)进行宏观形貌、微观组织的观察和分析。采用能谱分析仪对疏松位置进行区域检测和线性扫描,分析疏松位置及其周围区域的元素分布规律。试验表明:钎角根部存在等轴晶和少量分散状疏松,钎角中部存在大量枝晶和少量疏松,钎角尾部存在大量聚集状疏松并在其末端存在大量氧化物夹渣。Abstract: 1Cr18Ni9Ti stainless steel tube and 1Crl8Ni9Ti stainless steel bends were welded by high-frequency induction brazing, and the loose defects occurs in the fillet of brazed joint after brazing. The macro morphology and microstructure of brazed joint were observed and analyzed to study the microstructure and morphology of lose by optical microscope (OM) and field emission scanning electron microscope (SEM) and energy dispersive spectrometer (EDS). The loose defects were analyzed by energy dispersive spectrometer (EDS), then the distribution regular of the defects was studied. The results show that the roots of fillet exist isometric crystal and a few scattered lose, the middle of fillet exist a lot of dendritic crystal and a few loose, the tail of fillet exist a lot of aggregate shape loose and a lot of oxide slag.
-
Keywords:
- stainless steel tube /
- high-frequency induction brazing /
- fillet /
- loose
-
-
[1] 张启运,庄鸿寿,钎焊手册[M].北京:机械工业出版社,1988:461-481. [2] 孙磊,秦优琼.合金元素Cu对不锈钢钎焊接头组织及性能影响的研究[J].热加工工艺,2014,43(23):68-71. [3] Jiang Wenchun, Gong Jianming, Tu Shandong, et al. Modelling of temperature field and residual stress of vacuum brazing for stainless steel plate-fin structure[J]. Journal of Materials Processing Technology, 2009, 209(2): 1105-1110.
[4] 黄和平.金属零部件高频感应钎焊技术标准的研究[J].焊接技术,2013.42(2):30-34. [5] 郭万林,李天文.钛合金钎缝中元素的扩散行为研究[J].稀有金属,2001,25(5):345-347. [6] 敖斌,刘玉婵,樊国富,等.银铜基钎料在发动机导管上安装钎焊及脱焊工艺[J].焊接,2013(11):65-68. [7] 王小霞,丁毅,朱婧,等.不锈钢/碳钢的高频感应钎焊工艺及性能研究[J].热加工工艺,2011,40(17):152-154. [8] 张凌云,路文江,俞伟元,等,非晶镍基钎料钎焊接头性能及微观组织的研究[J1.热加工工艺,2009,38(13):19-21. [9] 刘文胜,刘书华,等.基于镍基微品钎料的钨/钢真空焊接接头的组织及性能[J].中国有色金属学报,2014.24(12):3051-3058. [10] Chung T, Kim J, Bang J, et al. Microstructures of brazing zone between titanium alloy and stainless steel using various filler metals[J]. Transactions of Nonferrous Metals Society of China,2012,22(S3):639-644.
[11] 庄鸿寿.异种金属的钎焊[J].焊接,2009(2):22-25. [12] 刘浩博,秦优琼,孙磊,等.采用BNi-7钎料钎焊316L不锈钢[J].焊接,2014(1):43-46. [13] 陈卓,李红.铁基钎料成分对304不锈钢钎焊接头组织和性能的影响[J].焊接,2016(3):45-48. [14] 陈祝年.焊接工程师手册(第2版)[M].北京:机械工业出版社,2009. [15] 邹僖.钎焊[M].北京:机械工业出版社,1988:114-116. [16] 何鹏,贾进国,余泽兴,等.高频感应钎焊的研究分析[J].机电工程技术,2003,32(1):23-27. [17] 谷海明,唐新华.不锈钢真空钎焊工艺特点及其应用[J].热加工工艺,2011,40(23):164-170. [18] 赵文龙,吴慕天,张伟,等.气滑铸造6082铝合金原锭疏松组织的成因及预防措施[J].中国科技博览,2012(2):34.
